DIGITRON SEMICONDUCTORS
UZ7706, UZ7806 SERIES
6 WATT POWER ZENERS
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
MAXIMUM RATING
Zener Voltage (V
Z
):
Continuous Current:
Surge Current ( 8.3 ms):
Surge Power:
Power:
Storage and Operating Temperature:
6.8 to 100V
See Table
See Table
See Graph
See Lead Temperature Derating Curve
-65°C to +175°C
ELECTRICAL CHARACTERISTICS
Part number
Nominal
Zener
Voltage
†
V
Z
@ I
ZT
+5%
Tolerance
+10%
Tolerance
Volts
Test
Current
I
ZT
mA
Max. Zener
Impedance
§
Z
Z
@ I
ZT
Ohms
Maximum Reverse Leakage
Current
I
R
@ V
R
μA
+5%
V
R
Volts
+10%
V
R
Volts
I
ZM
mA
Maximum
Continuous
Current
Maximum
Surge
Current
‡
I
S
Amps
T
C
@ I
ZT
%/°C
Typical
Temperature
Coefficient
UZ7706
UZ7707
UZ7708
UZ7709
UZ7710
UZ7712
UZ7713
UZ7714
UZ7715
UZ7716
UZ7718
UZ7720
UZ7722
UZ7724
UZ7727
UZ7730
UZ7733
UZ7736
UZ7740
UZ7745
UZ7750
UZ7756
UZ7760
UZ7770
UZ7775
UZ7780
UZ7790
UZ7110
UZ7806
UZ7807
UZ7808
UZ7809
UZ7810
UZ7812
UZ7813
UZ7814
UZ7815
UZ7816
UZ7818
UZ7820
UZ7822
UZ7824
UZ7827
UZ7830
UZ7833
UZ7836
UZ7840
UZ7845
UZ7850
UZ7856
UZ7860
UZ7870
UZ7875
UZ7880
UZ7890
UZ7210
6.8
7.5
8.2
9.1
10
12
13
14
15
16
18
20
22
24
27
30
33
36
40
45
50
56
60
70
75
80
90
100
350
325
300
275
250
200
200
175
150
150
130
120
100
100
90
80
70
60
60
50
50
40
40
35
30
30
25
20
0.6
0.7
0.8
1.0
1.0
1.3
1.5
1.5
2.0
2.5
3.5
4.0
4.5
5.0
6.0
8.0
10.0
12.0
15.0
20.0
22.0
30.0
35.0
40.0
45.0
60.0
75.0
90.0
1000
800
200
150
100
75
50
40
30
20
20
20
20
20
20
20
10
10
10
10
10
10
10
10
10
10
10
10
5.2
5.7
6.2
6.9
7.6
9.1
9.9
10.6
11.4
12.1
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
30.4
34.2
38.0
42.6
45.6
53.2
56.0
60.8
68.4
76.0
4.9
5.4
5.9
6.6
7.2
8.6
9.3
10.1
10.8
11.5
12.9
14.4
15.8
17.3
19.4
21.6
23.7
25.9
28.8
32.4
36.0
40.3
43.2
50.4
54.0
57.6
64.8
72.0
1350
1250
1150
1020
950
770
700
640
600
550
500
440
390
360
310
280
260
240
210
180
170
160
150
130
120
110
100
90
50
41
31
29
26
23
21
20
17
15
13
12
11
10
9
8.5
7.5
7.0
6.4
5.5
4.6
4.1
3.7
3.3
3.1
2.9
2.6
2.3
0.040
0.040
0.050
0.050
0.060
0.070
0.070
0.070
0.070
0.070
0.080
0.080
0.080
0.080
0.090
0.090
0.090
0.090
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.100
† All zener voltages are measured with an automated test set using a 35 millisecond test time. Longer or shorter test times will have a corresponding effect on the measured value
due to heating effects.
§ Zener impedance is derived from the 60 cycle AC voltage created when AC current with RMS value of 10% of DC zener test current is superimposed on the test current.
Ratings are based on 100°C case temperature: for leaded devices multiply by 0.6.
‡ Figures shown are for a peak sinusoidal surge current of 8.3ms duration using non-repetitive. The 8.3 ms square pulse rating is 71% of the value shown.
