DC Fan
120
San Ace 120
mm sq.
25mm thick (S type), 25mm thick (GV type)
25mm thick (G type),
38mm thick (HV type)
38mm thick (GV type), 38mm thick (G type)
38mm thick (SG type)
■
General Specifications
・
Material
……………………
Frame: Aluminum,
Impeller: Plastics (Flammability: UL94V-1)
・
Expected Life
……………
Refer to specifications L10:Survival rate:90% at 60
℃
,
（
rated voltage, and continuously run in a free air state
）
・
Lead Wire
…………………
red
black
Sensor
yellow
Control
brown
・
Storage Temperature
…−
30
℃
to
＋
70
℃（
Non-condensing
）
120
×
120
×
38
mm
■
Specifications
Model No.
［
V
½
［
V
½
〔
Mass
：
460g
〕
HV
type
Operating Temperature Expected Life
Note)
［℃½
［
h
½
The following nos.
have PWM controls and pulse sensors.
Rated Voltage Operating Voltage Range
PWM duty
Rated Current Rated Input Rated Speed
Max. Air Flow
Max. Static Pressure
SPL
［
W
½
［
min
-1
½
［
m³/min
½ ［
CFM
½ ［
Pa
½ ［
inchH²O
½ ［
dB(A)
½
cycle
※
［
%
½ ［
A
½
9HV1248P1G001
48
9HV1248P1H001
36 to 60
100
0
100
0
2.0
0.23
1.4
0.23
96
11
67
11
11,500
3,800
10,000
3,800
8.3
2.7
7.2
2.7
293
95
254
95
1,300
161
1,050
161
5.22
0.65
4.22
0.65
75
46
72
46
−
20 to
＋
70
40,000/60
℃
(70,000/40
℃
)
Note: Expected life at 40
℃
ambient is just reference value.
・
Available options:
⇒
Without Sensor
※
PWM Frequency
：
25kHz
Pulse Sensor
■
Dimensions
（
Unit : mm
）
■
Reference dimension of
mounting holes and vent opening
（
Unit : mm
）
Inlet side, Outlet side
104.8
±
0.3
4-
φ
4.5
8-
φ
4.5
±
0.3
Mounting Hole
取付用穴
φ
13
0
120
±
0.8
104.8
±
0.3
+30
300 0
(10)
104.8
±
0.3
120
±
0.8
Rotating Direction
回転方向
6.5
±
0.3
Lead Wire
3.5
±
0.3
リード線
AWG24
UL1430
38
±
0.5
6.5
±
0.3
3.5
±
0.3
117
Air
風吹出方向
Flow Direction
■
Options
（
Unit : mm
）
Finger guards
Model
：
109-019C
：
109-019H
Color
（
Surface treatment
：
Nickel-chrome plating silver
）
：
Cation electropainting black
）
（
Model
：
109-019E
：
109-019K
Color
（
Surface treatment
：
Nickel-chrome plating silver
）
：
Cation electropainting black
）
（
Outlet side
＋1
5
0
Inlet side, Outlet side
φ1.6
φ1.6
152.5±0.5
＋1
5
0
φ1.6 φ1.6
4.3±0.3
130
＋1.5
152.5
ー0.5
151
4.3±0.3
φ
18.6
130
φ
4
2.2
3
11
φ
3
11
φ
104.8
±
0.3
117
48
φ
1
φ
148
