This complete image processor includes three Corre-
lated Double Samplers (CDS) and Programmable Gain
Amplifiers (PGA) to process CCD signals.
These three channel inputs also allow Contact Image
Sensor (CIS) inputs.
The VSP3100 is an interface compatible with the
VSP3000 which is 12-bit one-chip product.
The VSP3100 can be operated from 0°C to +85°C and
is available in an LQFP-48 package.
Reference
Circuit
Timing Generator
Clamp
RINP
CM
REFP
CDS
PGA
REFN
INN
10
Clamp
GINP
10-Bit
DAC
5
OE
V
DRV
CDS
PGA
MUX
14-Bit
A/D
14
Digital
Output
Control
B0-B13
(A0-A2, D0-D9)
10
Clamp
BINP
10-Bit
DAC
5
CDS
PGA
Gain
Control
Register
R
3
Offset
Register
R
G
B
10
10-Bit
DAC
Configuration
Register
5
8
Register
Port
10
P/S
WRT
RD
SCLK
SD
G
B
5
VSP3100
International Airport Industrial Park • Mailing Address: PO Box 11400, Tucson, AZ 85734 • Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 • Tel: (520) 746-1111
Digital Input Voltage ................................................. –0.3V to (V
CC
+ 0.3V)
Analog Input Voltage ................................................ –0.3V to (V
CC
+ 0.3V)
Input Current (any pins except suppplies) ......................................
±10mA
Operating Temperature ........................................................ 0°C to +85°C
Storage Temperature ...................................................... –55°C to +150°C
Junction Temperature .................................................................... +150°C
Lead Temperature (soldering) ....................................................... +150°C
Package Temperature (IR Reflow, peak, 10s) ............................... +260°C
Package Temperature (IR Reflow, peak, 5s) ................................. +235°C
NOTES: (1) Stresses above these ratings may cause permanent damage.
Exposure to absolute maximum conditions for extended periods may degrade
device reliability. These are stress ratings only, and functional operation of the
device at these or any other conditions beyond those specified is not implied.
(2) V
CC
, V
DRV
. (3) Among V
CC
. (4) Among AGND.
ELECTROSTATIC
DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING
NUMBER
340
SPECIFIED
TEMPERATURE
RANGE
0°C to +85°C
PACKAGE
MARKING
VSP3100Y
VSP3100Y
ORDERING
NUMBER
(1)
VSP3100Y
VSP3100Y/2K
TRANSPORT
MEDIA
250-Piece Tray
Tape and Reel
PRODUCT
VSP3100Y
PACKAGE
LQFP-48
"
"
"
"
NOTE: (1) Models with a slash (/) are available only in Tape and Reel in the quantities indicated (e.g., /2K indicates 2000 devices per reel). Ordering 2000 pieces of
“VSP3100Y/2K” will get a single 2000-piece Tape and Reel.
DEMO BOARD ORDERING INFORMATION
PRODUCT
VSP3100Y
PACKAGE
DEM-VSP3100Y
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN
assumes no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject
to change without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not
authorize or warrant any BURR-BROWN product for use in life support devices and/or systems.
