CXA2006 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Other integrated circuit (IC)> CXA2006

CXA2006: DescriptionSPECIALTY CONSUMER CIRCUIT, PQFP32; Categorysemiconductor Other integrated circuit (IC); File Size301KB，23 Pages; ManufacturerSONY; Websitehttp://www.sony.co.jp

Download Datasheet Parametric Compare View All

CXA2006 Overview

SPECIALTY CONSUMER CIRCUIT, PQFP32

CXA2006 Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	32
Maximum operating temperature	75 Cel
Minimum operating temperature	-20 Cel
Maximum supply/operating voltage	5 V
Minimum supply/operating voltage	4.5 V
Processing package description	7 × 7 MM, 0.80 MM PITCH, Plastic, Quad Flat Package-32
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Craftsmanship	BIPOLAR
packaging shape	SQUARE
Package Size	FLATPACK
surface mount	Yes
Terminal form	GULL WING
Terminal spacing	0.8000 mm
terminal coating	Tin BISMUTH
Terminal location	Four
Packaging Materials	Plastic/Epoxy
Temperature level	COMMERCIAL EXTENDED
Consumer IC Type	consumer circuits

Preview

Download Datasheet

View All

CXA2006Q

Digital CCD Camera Head Amplifier

Description

The CXA2006Q is a bipolar IC developed as a

head amplifier for digital CCD cameras. This IC

provides the following functions: correlated double

sampling, AGC for the CCD signal, GCA for the low-

band chroma signal, AMP for high-band chroma and

line signals, A/D sample and hold, blanking, A/D

reference voltage, and an output driver.

Features

•

High sensitivity made possible by a high-gain AGC

amplifier

•

Blanking function provided for the purpose of

calibrating the CCD output signal black level

•

Regulator output pin provided for A/D converter

reference voltage

•

Built-in GCA and AMP for amplifying video signals

(chroma and line signals) from external sources

•

Built-in sample-and-hold circuits (for camera signals

and for video signals) required by external A/D

converters

Absolute Maximum Ratings

•

Supply voltage

•

Operating temperature Topr

•

Storage temperature Tstg

•

Allowable power dissipation

Operating Conditions

Supply voltage

Applications

Digital CCD cameras

Structure

Bipolar silicon monolithic IC

32 pin QFP (Plastic)

–20 to +75

–65 to +150

640

°C

1, 2, 3

4.5 to 5

Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by

any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the

operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.

–1–

E94X41B8X-PS

CXA2006 Related Products

	CXA2006	CXA2006Q
Description	SPECIALTY CONSUMER CIRCUIT, PQFP32	SPECIALTY CONSUMER CIRCUIT, PQFP32
Number of functions	1	1
Number of terminals	32	32
Maximum operating temperature	75 Cel	75 °C
Minimum operating temperature	-20 Cel	-20 °C
surface mount	Yes	YES
Terminal form	GULL WING	GULL WING
Terminal location	Four	QUAD
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED
