Solid State Sensors
Digital Current Sensors
FEATURES
Digital output
AC or DC current sensing
Through-hole design
Output voltage isolation from input
Minimum energy dissipation
Maximum current limited only by
conductor size
Accurate, low cost sensing
Operating temperature range – 25 to
85°C
DIGITAL CURRENT DETECTORS ORDER GUIDE, SINKING OUTPUT
Operate
Current
@ 25°C
(Amp-Turns)
Min.
CSDA1BA
CSDA1BC
CSDC1BA
CSDC1BC
CSDA1AA
CSDA1AC
CSDC1AA
CSDC1AC
CSDC1DA
CSDA1DA
CSDC1DC
CSDA1DC
2
2
2
2
1
1
1
1
3
3
3
3
0.32
2.2
0.32
2.2
0.32
2.2
0.32
2.2
0.32
0.32
2.2
2.2
Nom.
0.50
3.5
0.50
3.5
0.50
3.5
0.50
3.5
0.50
0.50
3.5
3.5
Max.
0.88
6.5
0.88
6.5
0.88
6.5
0.88
6.5
0.88
0.88
6.5
6.5
.25 to 1.0
1.7 to 7.5
.25 to 1.0
1.7 to 7.5
.25 to 1.0
1.7 to 7.5
.25 to 1.0
1.7 to 7.5
.25 to 1.0
.25 to 1.0
1.7 to 7.5
1.7 to 7.5
0.08
0.60
0.08
0.60
0.08
0.60
0.08
0.60
0.08
0.08
0.60
0.60
6 to 16
6 to 16
5
±
0.2
5
±
0.2
6 to 16
6 to 16
5
±
0.2
5
±
0.2
5
±
0.2
6 to 16
5
±
0.2
6 to 16
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
20mA
20mA
20mA
20mA
20mA
20mA
20mA
20mA
20mA
20mA
20mA
20mA
Operate
Current
–25°C to
+85°C
(Amp-Turns)
Release
Current
– 25°C to
+85°C
(Amp-Turns Min.)
Supply
Volt.
(Volts DC)
Output
Volt.
(Volts)
CS Series
Digital Current Sensors
Each MICRO SWITCH CS series digital
current sensor provides a logic level out-
put that changes from approximately Vcc
to 0.4 volts when the sensed current ex-
ceeds the operate point. Each digital sen-
sor will operate on AC or DC current, but
the output will turn off at every zero cross-
ing when sensing AC current. Housing
material: PET polyester.
Catalog
Listings
Pinout
Style
Output
Current
(mA)
Sinking
Response
Time
(µ Sec.)
100
100
100
100
100
100
100
100
100
100
100
100
