POWER INDUCTORS
Military Grade Power Inductors
ML558PTA
■
High temperature materials allow operation in ambient
temperatures up to 155°C.
■
Excellent current handling; very low DCR
Core material
Ferrite
Terminations
Tin-silver over copper (pins 1 and 2); matte tin over
nickel over phos bronze (pin 3).
Weight
1.6 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
200/7″ reel; 700/13″ reel
Plastic tape: 24 mm wide,0.4 mm thick, 16 mm pocket spacing,
5.45 mm pocket depth
Inductance
2
±20% (µH)
0.33
0.80
1.0
1.2
1.3
1.5
1.8
2.0
2.2
2.5
3.2
4.0
4.3
5.7
DCR max
3
(mOhm)
4.0
4.0
4.0
6.0
4.0
6.0
6.0
9.0
4.0
7.5
6.0
9.0
7.5
9.0
SRF (MHz)
4
min
typ
119
70.0
66.5
63.7
56.7
52.5
49.0
45.5
40.6
38.5
37.1
32.9
30.8
24.5
170
100
95.0
91.0
81.0
75.0
70.0
65.0
58.0
55.0
53.0
47.0
44.0
35.0
Isat
(A)
5
10% drop 20% drop
29.5
24.9
16.5
20.5
12.9
13.5
13.3
15.3
8.9
11.4
7.3
8.3
6.4
5.4
30.0
25.2
17.0
21.0
16.8
14.0
13.8
15.8
9.6
11.8
7.8
8.5
6.8
5.8
Irms
(A)
6
20°C rise 40°C rise
12.5
12.5
12.5
11.0
12.5
11.0
11.0
8.5
12.5
9.0
11.0
8.5
9.0
8.5
16.3
16.3
16.3
15.0
16.3
15.0
15.0
11.5
16.3
12.0
15.0
11.5
12.0
11.5
Part number
1
ML558PTA331MLZ
ML558PTA801MLZ
ML558PTA102MLZ
ML558PTA122MLZ
ML558PTA132MLZ
ML558PTA152MLZ
ML558PTA182MLZ
ML558PTA202MLZ
ML558PTA222MLZ
ML558PTA252MLZ
ML558PTA322MLZ
ML558PTA402MLZ
ML558PTA432MLZ
ML558PTA572MLZ
30% drop
30.5
25.6
17.5
21.3
17.2
14.5
14.3
16.2
10.0
12.1
8.5
8.8
7.0
6.0
1. When ordering, please specify
testing
code:
ML558PTA572MLZ
Testing: Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
C
= Custom screening (please specify when ordering)
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc on an Agilent/HP 4284A or equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using an Agilent/HP 8753D network analyzer.
5. Typical DC current at which the inductance drops the specified amount from its value without current.
6. Typical current that causes the specified temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information. Document ML535-1
Revised 04/28/10
