DC/DC Converters
TMH Series, 2 Watt
Features
◆
Single-in-line package (SIP)
◆
Fully SMD-design
◆
Isolated single and dual output
◆
I/O isolation 1‘000 VDC
◆
High efficiency up to 83 %
◆
Industry standard pinout
◆
100% burn-in (8 h)
◆
Lead free design, RoHS compliant
◆
3-year product warranty
The TMH series are ultra miniature, isolated 2 Watt DC/DC-converters in a Single-
in-Line package (SIP). Requiring only 1.5 cm2 board space they offer the ideal
solution in many space critical applications for board level power distribution. The
use of SMD-technology makes it possible to offer a product with high performance
at low cost.
Models
Ordercode
TMH 0505S
TMH 0512S
TMH 0515S
TMH 0505D
TMH 0512D
TMH 0515D
TMH 1205S
TMH 1212S
TMH 1215S
TMH 1205D
TMH 1212D
TMH 1215D
TMH 2405S
TMH 2412S
TMH 2415S
TMH 2405D
TMH 2412D
TMH 2415D
http://www.tracopower.com
24 VDC ±10%
12 VDC ±10%
5 VDC ±10%
Input voltage
Output voltage
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
Output current max.
400 mA
165 mA
130 mA
±200 mA
±80 mA
±65 mA
400 mA
165 mA
130 mA
±200 mA
±80 mA
±65 mA
400 mA
165 mA
130 mA
±200 mA
±80 mA
±65 mA
Efficiency typ.
76 %
80 %
80 %
77 %
79 %
79 %
78 %
82 %
83 %
79 %
82 %
82 %
77 %
81 %
82 %
79 %
81 %
82 %
Page 1 of 3
DC/DC Converters
TMH Series
Input Specifications
Input current no load / full load
5 Vin models
50 mA / 510 mA typ.
12 Vin models
20 mA / 200 mA typ.
24 Vin models
10 mA / 100 mA typ.
5 Vin models
9 V max.
12 Vin models
18 V max.
24 Vin models
30 V max.
0.3 A max.
can be reduced by ext. 1–3.3 µF polyester film
capacitor
internal capacitors
±3 %
1 % max.
1.2 % / 1 % change Vin
10 % max.
5 Vin models
75 mV pk-pk max.
12 /24 Vin models
150 mV pk-pk max
±0.02 % / K
limited 1 sec. max.
– Single output models
– Dual output models
– Operating
– Case temperature
– Storage
470 µF max.
390 µF max.
–40°C to +85°C
+90°C max.
–40°C to +125°C
3 %/K above +70°C
95 % rel H max.
3 %/K above +70°C
>2’000’000 h
1‘000 VDC
80 pF typ.
>1‘000 Mohm
80 kHz typ. (frequency modulation)
±30 % max.
www.tracopower.com/products/tmh-reach.pdf
RoHS directive 2002/95/EC
– Reach
– RoHS
Input/Output
Input/Output
Input/Output
– Input variation
– Load variation 20 – 100 %
2 Watt
Surge voltage
(1 sec. max.)
Reverse voltage protection
Reflected input ripple current
Input filter
Output Specifications
Voltage set accuracy
Voltage balance
(dual output models)
Regulation
Ripple and noise
(20 MHz Bandwidth)
Temperature coefficient
Short circuit protection
Capacitive load
General Specifications
Temperature ranges
Derating
(convection cooling)
Humidity
(non condensing)
Derating
(convection cooling)
Reliability, calculated MTBF
(MIL-HDBK-217F at +25°C, ground benign)
Isolation voltage
(60sec.)
Isolation capacitance
Isolation resistance
Switching frequency
Frequency change over line and load
Environmental compliance
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
http://www.tracopower.com
Page 2 of 3
DC/DC Converters
TMH Series
Physical Specifications
Casing material
Package weight
Soldering temperature
non conductive black plastic
(UL 94-V0 rated)
2.7 g
(0.1oz)
max. +265°C / 10 sec.
2 Watt
Outline Dimensions mm (inches)
Pin-Out
10.2
(0.4)
Pin
1
2
4
5
6
0.5
(0.02)
Single
+Vin (Vcc)
–Vin (GND)
–Vout
No pin
+Vout
Dual
+Vin (Vcc)
–Vin (GND)
–Vout
Common
+Vout
0.5
(0.02)
0.5
(0.02)
2.3
±
0.5
2.54
(0.1)
5.08
(0.2)
2.54 2.54
(0.1)
(0.1)
(0.09
±0.02
)
19.5
(0.77)
0.25
(0.01)
1
2
4
5
6
Tolerances ±0.25 (±0.01)
pins ±0.05 (±0.002)
Specifications can be changed any time without notice.
Rev. 03/12
Jenatschstrasse 1 · CH-8002 Zurich · Switzerland
Tel. +41 43 311 45 11 · Fax +41 43 311 45 45 · info@traco.ch · www.tracopower.com
(0.05)
0.5
(0.02)
1.25
7.5
(0.3)
Bottom view
3.2
(0.13)
Page 3 of 3
