RP130x Series
Low Noise 150mA LDO
The RP130x Series are CMOS-based LDO regulators featuring 150mA output. The RP130x features an excellent line transient
response, a high ripple rejection at 80dB, and ultra low noise. The polarity of the CE pin can be selected. The version with
auto-discharge function is also available. Compared to existing high-speed lines, the RP130x provides low supply current at Typ.
38μA. The series covers a wide voltage range, including the input voltage range of 1.7V to 6.5V and the output voltage range of 1.2V to
5.0V. Ceramic capacitors can be used.
FEATURES
•
Supply Current (I
SS
) ························ Typ. 38μA (V
IN
=SET V
OUT
+1V)
•
Standby Current (I
standby
) ················· Typ. 0.1μA (Same as above, in standby)
•
Dropout Voltage (V
DIF
) ···················· Typ. 0.32V (I
OUT
=150mA, V
OUT
=2.8V)
•
Ripple Rejection (RR)····················· Typ. 80dB (f=1kHz)
•
Input Voltage Range (V
IN
) ··············· 1.7V to 6.5V
•
Output Voltage Range (V
OUT
)·········· 1.2V to 5.0V (internally fixed)
•
Output Voltage Accuracy ················± 1%
•
Temp. coeff. of Output Voltage ·······Typ.
±
20ppm/°C
•
Line Regulation·······························Typ. 0.02%/V
•
Fold-back Protection Circuit············Current limit Typ. 40mA
•
Auto-Discharge function ·················D Version
•
Packages ········································DFN(PLP)1010-4,
•
SC-82AB, SOT-23-5
Ceramic capacitors can be used. ···0.47μF or more
(The above shows specification at Topt=25
°
C. Design assurance value at -40
°
C
<
Topt
<
85
°
C is also available. For details, please refer to the datasheet.)
=
=
BLOCK DIAGRAMS
RP130xxx1A
(
CE
pin "L" active)
V
DD
V
OUT
V
DD
RP130xxx1B
(CE pin "H" active)
V
OUT
V
DD
RP130xxx1D
(With Auto-Discharge function)
V
OUT
Vref
Current Limit
Vref
Current Limit
Vref
Current Limit
CE
GND
CE
GND
CE
GND
SELECTION GUIDES
Package
DFN(PLP)1010-4
SC-82AB
SOT-23-5
Quantity per Reel
Part No.
10,000 pcs
RP130K.xx.1.
∗
-TR
3,000 pcs
RP130Q.xx.1.
∗
-TR-F
3,000 pcs
RP130N.xx.1.
∗
-TR-F
.xx.
: Specify the output voltage within the range 1.2V (.12.) to 5.0V (.50.)
in 0.1V steps.
.
∗
.
: Select the polarity of the CE pin from (.A.) ”L” active, (.B.) ”H” active or
(.D.) ”H” active with auto-discharge function.
PACKAGES (Top View)
DFN(PLP)1010-4
4
3
TYPICAL CHARACTERISTIC
SOT-23-5
5
4
SC-82AB
4
3
RP130x281x
0.40
0.35
0.30
0.25
0.20
0.15
0.10
0.05
0
0
Dropout Voltage vs. Output Current
85°C
25°C
- 40°C
∗
1
2
1
2
1
2
3
1
2
3
4
V
OUT
GND
CE
or CE
V
DD
1
2
3
4
CE
or CE
GND
V
OUT
V
DD
1
2
3
4
5
V
DD
GND
CE
or CE
NC
V
OUT
Dropout Voltage V
DIF
(V)
25
50
75
100 125
Output Current I
OUT
(mA)
150
∗
) The tab is substrate level (GND).
APPLICATIONS
•
Power source for hand-held communication equipment, cameras, and VCRs
•
Power source for home appliances
•
Power source for battery-operated devices
•
Voltage reference
No.EK-173-100119
CMOS LDO Regulator
