4.00 inch 4x4 Dot Matrix LED Display

Preview

Download Datasheet

View All

LightKey

Datasheet of 4.00 inch 4x4 Dot Matrix LED Display

LM40044A/B Series – 4.00 inch 4x4 Dot Matrix LED Display

ATTENTION

OBSERVE PRECAUTIONS

FOR HANDLING

ELECTROSTATIC

DISCHARGE

SENSITIVE

DEVICES

Features

108.80 mm (4.00 inch) digit high

Dot size: Diameter 20.00 mm

Pitch: 27.20 mm

Wide viewing angle

Range of emitted colors

I.C. compatible

Low power consumption

White dot, grey or black face

RoHS compliant

Available options

Alternative emitting luminosity:

Standard or high brightness version

Alternative emitted color

Alternative dot color

Alternative face

Both CC and CA versions are available

Cropped terminal pins

Package Dimensions

Ø20.0(0.80 )

2 7 . 2 × 3 = 8 1. 6

1 0 8 . 8( 4 . 3 5 )

PIN 1

27.2×3=81.6

108.8(4.35 )

17.0

COL .

ROW 1

Ø0.80

5.08×3=15.24

Notes:

1. All dimensions are in millimeters (inches), Tolerance is + 0.25mm (0.01inch) unless other wise noted.

2. Specifications are subject to change without notice.

3. The gap between the reflector and PCB shall not exceed 0.25mm.

SPEC NO: DS10121844

REV: A.4

CHECKED: Emily Zhou

TEL: 0086-574-86322282

94 . 6

APPROVED: M.H. Lin

PAGE: 1/3

HTTP://WWW.LTKEY.COM

DATE: Jul/20/2011
