MLCC Low Profile
General Specifications
GENERAL DESCRIPTION
AVX introduces the LT series comprising a range of low profile
products in our X5R and X7R dielectric. X5R is a Class II dielectric
with temperature varation of capacitance within ±15% from –55°C to
+85°C. Offerings include 0201, 0402, 0603, 0805 1206, and 1210
packages in compact, low profile designs. The LT series is ideal for
decoupling and filtering applications where height clearance is limited.
AVX is also expanding the low profile products in our X7R dielectric.
X7R is a Class II dielectric with temperature variation of capacitance
within ±15% from -55ºC to +125ºC. Please contact the factory for
availability of any additional values not listed.
PART NUMBER
(see page 2 for complete part number explanation)
LT05
Size
LT01 - 0201
LT02 - 0402
LT03 - 0603
LT05 - 0805
LT06 - 1206
LT10 - 1210
Z
Voltage
4V = 4
6.3V = 6
10V = Z
16V = Y
25V = 3
D
Dielectric
X5R = D
X7R = C
475
Capacitance
Code (In pF)
2 Sig. Digits +
Number of
Zeros
K
Capacitance
Tolerance
K = ±10%
M = ±20%
A
Failure
Rate
A = Not
Applicable
T
Terminations
T = Plated Ni
and Sn
2
S
Special
Packaging
Code
2 = 7" Reel
See table below
4 = 13" Reel
7 = Bulk Cass.
9 = Bulk
Contact
Factory
For
Multiples
NOTE: Contact factory for availability of tolerance options for specific part numbers.
SIZE
Cap
(μF)
WVDC
104
0.10
0.22
0.47
105
1.0
1.5
2.2
4.7
106
10
22
47
WVDC
LT01
4
Z
4
LT02
6.3
Q
10
16
S
4
LT03
6.3
16
25
X
X
X
6.3
LT05
10
16
25
10
LT06
16
25
LT10
16
25
X
X
X
X
X
C
S
S
S
X
S
X
S
X/W
X
S
X
W
W
W
W
W
4
4
6.3
10
16
4
6.3
16
25
6.3
10
16
25
10
16
25
16
25
SIZE
= X7R
Letter
Max.
Thickness
J
0.15
(0.006)
LT01
LT02
LT03
LT05
LT06
LT10
Z
0.22
(0.009)
Q
C
0.25
0.36
(0.010)
(0.014)
PAPER
S
0.56
(0.022)
X
0.95
(0.038)
W
1.02
(0.040)
EMBOSSED
36
