BAT54LPQ
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Product Summary
(@T
A
= +25°
C)
V
RRM
(V)
30
I
O
(mA)
200
V
F(MAX)
(V)
1
I
R(MAX)
(µA)
2.0
Features and Benefits
Low Forward Voltage Drop
Fast Switching
Ultra-Small Leadless Surface Mount Package
PN Junction Guard Ring for Transient and ESD Protection
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
The BAT54LPQ is suitable for automotive applications
requiring specific change control; it is AEC-Q101 qualified,
PPAP capable, and manufactured in IATF 16949 certified
facilities.
https://www.diodes.com/quality/product-definitions/
Applications
SMPS
Free Wheeling Diodes
Reverse Polarity Protection
DC-DC Converters
General Switching Applications
Mechanical Data
Case: X1-DFN1006-2
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Bar
Terminals: Finish - NiPdAu Annealed over Copper Leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.001 grams (Approximate)
X1-DFN1006-2
Top View
Bottom View
Ordering Information
(Note 4)
Part Number
BAT54LPQ-7
BAT54LPQ-7B
Notes:
Compliance
Automotive
Automotive
Case
X1-DFN1006-2
X1-DFN1006-2
Packaging
3000/Tape & Reel
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at https://www.diodes.com/design/support/packaging/diodes-packaging/.
Marking Information
Top View
L1 or L1 = Product Type Marking Code
Bar Denotes Cathode Side
Top View
Bar Denotes Cathode Side
BAT54LPQ
Document number: DS42046 Rev. 2 - 2
1 of 5
www.diodes.com
October 2019
© Diodes Incorporated
BAT54LPQ
Maximum Ratings
(@T
A
= +25° unless otherwise specified.)
C,
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Output Current
Repetitive Peak Forward Current
Forward Surge Current
Symbol
V
RRM
V
RWM
V
R
I
O
I
FRM
I
FSM
Value
30
200
300
600
Unit
V
mA
mA
mA
@ t < 1.0s
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient Air (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
JA
T
J
, T
STG
Value
250
400
-65 to +125
Unit
mW
°
C/W
°
C
Electrical Characteristics
(@T
A
= +25° unless otherwise specified.)
C,
Characteristic
Reverse Breakdown Voltage (Note 6)
Symbol
V
(BR)R
Min
30
Typ
Max
240
320
Forward Voltage
V
F
400
500
1,000
Reverse Leakage Current (Note 6)
Total Capacitance
Reverse Recovery Time
Notes:
Unit
V
Test Condition
I
R
= 100µA
I
F
= 0.1mA
I
F
= 1mA
mV
I
F
= 10mA
I
F
= 30mA
I
F
= 100mA
I
R
C
T
t
RR
2.0
10
5.0
µA
pF
ns
V
R
= 25V
V
R
= 1.0V, f = 1.0MHz
I
F
= 10mA through I
R
= 10mA
to I
R
= 1.0mA, R
L
= 100Ω
5. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/package-outlines.html.
6. Short duration pulse test used to minimize self-heating effect.
BAT54LPQ
Document number: DS42046 Rev. 2 - 2
2 of 5
www.diodes.com
October 2019
© Diodes Incorporated
BAT54LPQ
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
I
R
, INSTANTANEOUS REVERSE CURRENT (µA)
I
R
, Instantaneous Reverse Current (µA)
1,000
100
T
A
=125°
C
10
T
A
=75°
C
100
1
0.1
0.01
T
A
=0°
C
T
A
=25°
C
10
0.001
T
A
= -40°
C
1
0.0001
0.1
0
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
V
F,
V
R
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
0.00001
0
3 6
9 12 15 18 21 24 27 30
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
Figure 2 Typical Reverse Characteristics
300
P
D
, POWER DISSIPATION (mW)
250
200
150
100
50
0
0
25
50
75
100
125
C)
T
A
, AMBIENT TEMPERATURE
(°
)
(癈
Fig. 3 Power Derating Curve
BAT54LPQ
Document number: DS42046 Rev. 2 - 2
3 of 5
www.diodes.com
October 2019
© Diodes Incorporated
BAT54LPQ
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
X1-DFN1006-2
A
A1
D
R
E
b
X1-DFN1006-2
Dim Min Max Typ
A
0.47 0.53 0.50
A1
0
0.05 0.03
b
0.45 0.55 0.50
D
0.95 1.075 1.00
E
0.55 0.675 0.60
e
-
-
0.40
L
0.20 0.30 0.25
R
0.05 0.15 0.10
All Dimensions in mm
L
e
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
X1-DFN1006-2
X1
X
Dimensions
Y
G
C
C
G
X
X1
Y
Value
(in mm)
0.70
0.30
0.40
1.10
0.70
BAT54LPQ
Document number: DS42046 Rev. 2 - 2
4 of 5
www.diodes.com
October 2019
© Diodes Incorporated
BAT54LPQ
