PME291
• EMI suppressor, class Y2, metallized paper
• 0.001 – 0.022 µF, 300 VAC, +115 °C
• Self-extinguishing encapsulation.
The material is recognized according
to UL 94 V-0.
• Very precise positioning of the leads in
relation to the case giving efficient
utilisation of PC board space.
• Excellent self-healing properties.
Ensures long life even when subjected to
frequent overvoltages.
• High dU/dt capability.
• Good resistance to ionisation due to
impregnated dielectric.
• The capacitors meet the most stringent
IEC humidity class, 56 days.
• The impregnated paper ensures excellent
stability giving outstanding reliability
properties, especially in applications
having continuous operation.
TYPICAL APPLICATIONS
The capacitors are intended for use as
interference suppressors in Y2 applications,
line-to-earth.
CONSTRUCTION
Multi-layer metallized paper. Encapsulated
and impregnated in self-extinguishing material
meeting the requirements of UL 94V-0.
GENERAL DATA
Rated voltage
Capacitance range
Capacitance tolerance
Temperature range
Climatic category IEC
Approvals
Dissipation factor tan
δ
Insulation resistance
300 VAC 50/60 Hz
0.001 – 0.022 µF
± 20%
–40 to +115°C
40/115/56/B
S, VDE, UL, CSA
≤
1.3 % at 1 kHz
12000 MΩ
Measured at 500 VDC after 60 s, +23°C
Tabulated self-resonance frequencies f
0
refer to
5 mm lead length.
Recommended voltage:
≤
1000 VDC
The 100% screening factory test is carried out at
2000 VAC, 50 Hz, 2 s and at 3000 VDC, 1 s. The
voltage level is selected to meet the requirements in
applicable equipment standards. All electrical
characteristics are checked after the test.
l = standard : 30 +5/-0 mm
option : short leads, tolerance +0/-1 mm
(standard 6 mm, code R06)
Other lead lengths on request
Resonance frequency
In DC applications
Test voltage between terminals
ENVIRONMENTAL TEST DATA
Vibration
IEC 60068-2-6
Test Fc
IEC 60068-2-29
Test Eb
IEC 60068-2-20, Test Ta
EN 132400
IEC 60384-14 (1993)
EN 132400
IEC 60068-2-3, Test Ca
+40°C and 90 – 95% R.H.
56 days
3 directions at 2 hour each
10 – 500 Hz at 0.75 mm or 98 m/s
2
4000 bumps at 390 m/s
2
No visible damage
No open or short circuit
No visible damage
No open or short circuit
Wetting time < 1 s
Bump
Solderability
Active flammability
Passive flammability
Solder globule method
Humidity
163
PME291
ARTICLE TABLE
Quantity per package
reel
R30
R06 taped Weight
pcs
pcs pcs
g
800
800
800
800
800
800
600
500
500
400
250
250
1600
1600
1200
1200
1200
1200
1200
1000
800
600
500
400
700
700
600
600
600
600
600
600
600
400
400
400
1.2
1.1
1.3
1.3
1.5
1.5
1.6
1.9
2.0
2.6
3.0
3.6
Approvals
f
O
MHz
56.0
46.0
39.0
36.0
31.0
28.0
26.0
23.0
18.0
15.0
12.0
9.8
Max
dU/dt
V/µs
2000
2000
2000
2000
2000
2000
2000
1400
1400
1400
1400
1400
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
Article code
1 st block
PME291EA4100M
PME291EA4150M
PME291EA4220M
PME291EA4250M
PME291EA4330M
PME291EA4390M
PME291EA4470M
PME291EB4470M
PME291EB4680M
PME291EB5100M
PME291EB5150M
PME291EB5220M
Capaci- Max dimensions in mm
tance
µF
B
H
L
p
0.0010
0.0015
0.0022
0.0025
0.0033
0.0039
0.0047
0.0047
0.0068
0.010
0.015
0.022
4.5
4.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
7.5
8.5
8.5
11.5
10.5
10.5
10.5
12.5
12.5
13.5
13.0
14.0
13.5
14.5
17.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
18.0
18.0
18.0
18.0
18.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
15.0
15.0
P = Approvals pending
APPROVALS/REFERENCE DOCUMENTS
Country
S
VDE
UL
CSA
= Sweden
= Germany
= USA
= Canada
Specification
EN 132400
EN 132400
UL 1414 (250 VAC)
C 22.2 No. 8 (250 VAC)
Approval reference
9909056/01
123537
E73869
53108
•
•
•
•
•
•
MARKING
RIFA
RIFA article code
Rated capacitance
Rated voltage
Y2
Climatic category according to
IEC 60068-1, appendix A
• Passive flammability class
• Approval marks
• Manufacturing code (year, month)
ORDERING INFORMATION
Article code
1st block
See article table
Pos. 13, capacitance tolerance code:
M = ± 20%
2nd block
Options:
Short leads: e.g. 6 mm, add R06
in pos. 14–16.
Reel taped: Add T0 or T1 in pos. 14–15.
PACKING
Capacitors in standard design (lead length
30 mm) and with lead length 5 or 6 mm are
packed bulk in a box with dimensions 245
x 145 x 80 mm. Quantity/package as per
article table.
Reels with taped capacitors are packed 10 in
a box with dimension 370 x 370 x 560 mm.
The standard quantity/reel is for 360 mm
reel. If 500 mm reel is required, it must be
specified when ordering and the quantity is
2 x the given quantity.
P M E 2 9 1 E A 4
1 2 3 4 5 6 7 8
2
2
0 M
R
0
6
16
17
18
19
20
9 10 11 12 13
14 15
