Radial Lead Transient Voltage Suppressors (TVS)
KC Series
Description
The KC Series of high current transient suppressors have been
specially designed for use in A.C. line protection and any
demanding applications (AC or DC). Any voltage rise due to
increased current conduction is contained to a minimum, providing
the best possible protection level. They can also be connected in
series and/or parallel to create very high capacity protection
solutions.
Features
u
u
u
u
u
u
u
u
u
u
u
u
u
Axial lead terminals
High current transient suppressor
Excellent Clamping Capability
Glass Passivated Junction
Bi-directional
Low Slope Resistance
Repetition Rate (duty cycle):0.01%
Hazardous Substances Free
RoHS Compliant
High Temperature soldering: 260°C/10 seconds at terminals
Epoxy Encapsulated
Silver plated leads
Solderable per MIL-STD-202 Method 208
Bi-directional
Functional Diagram
Maximum Ratings
(T
A
=25℃ unless otherwise noted)
Parameter
Symbol
T
J
T
STG
I
PP
Value
-55 to +150
-55 to +150
10
Unit
°C
°C
KA
Operating junction
Storage Temperature Range
Current Rating
1
Notes:
1. Rated IPP measured with 8
×
20μs pulse.
SOCAY Electronics Co., Ltd.
Revision September 25, 2013
www.socay.com
1/4
@ SOCAY Electronics Co., Ltd. 2013
Specifications are subject to change without notice.
Please refer to www.socay.com for current information.
Radial Lead Transient Voltage Suppressors (TVS)
KC Series
Electrical Characteristics
(T
A
=25℃ unless otherwise noted)
Breakdow
n Voltage
V
BR
(V)
MIN.@I
T
14
17
22
28
33
47
64
70
83
110
147
180
200
222
Test
Current
I
T
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Current
Rating
I
PP
8/20μs
(KA)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum
Energy
10/1000μs
(A)
1665
2164
2664
3163
3996
5661
8158
8658
9324
14152
17649
23310
27972
28638
Maximum
Clamping
Voltage
V
C
(V)
@I
PP
28
30
40
50
60
77
110
125
135
165
220
260
290
330
Reverse
Leakage
I
R
(μA)
@VDC
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Reverse Stand-Off
Voltage
Part Number
VAC(V)
KC-012
KC-015
KC-020
KC-025
KC-030
KC-042
KC-058
KC-066
KC-076
KC-100
KC-133
KC-170
KC-190
KC-200
8.5
11
14
17
21
30
40
45
54
72
100
130
145
150
VDC(V)
12.8
15
20
25
30
42
58
66
76
100
133
170
190
200
SOCAY Electronics Co., Ltd.
Revision September 25, 2013
www.socay.com
2/4
@ SOCAY Electronics Co., Ltd. 2013
Specifications are subject to change without notice.
Please refer to www.socay.com for current information.
Radial Lead Transient Voltage Suppressors (TVS)
KC Series
Ratings and Characteristic Curves (T
A
=25°C unless otherwise noted) (Continued)
Physical Specifications
Weight
Case
Terminal
Contact manufacturer
Epoxy encapsulated
Silver plated leads, solderable
MIL-STD-750, Method 2026
per
Soldering Parameters
T
P
Ramp-up
Critical Zone
T
L
to T
P
Reflow Condition
-Temperature Min (T
s(min)
)
Pre Heat
Ramp-down
Lead–free assembly
150°C
200°C
60 -180 Seconds
3°C/second max
3°C/second max
217°C
60 -150 Seconds
260 +0/-5°C
of
actual
peak
20 -40 Seconds
6°C/second max
8 minutes Max
280°C
T
L
Temperature
T
S(max)
-Temperature Max (T
s(max)
)
- Time (min to max) (T
s
)
T
S(min)
Preheat
Average ramp up rate ( Liquidus Temp T
L
)
to peak
T
S(max)
to TL - Ramp-up Rate
25
Time to peak temperature
(t 25℃ to peak)
Time
Reflow
- Temperature (T
L
) (Liquidus)
- Time (min to max) (
T
L
)
Flow/Wave Soldering (Solder Dipping)
Peak Temperature :
Dipping Time :
Soldering :
265°C
10 seconds
Peak Temperature (T
P
)
Time within 5°C
Temperature (t
p
)
Ramp-down Rate
Time 25°C to peak Temperature (T
P
)
1 time
Do not exceed
Ratings and Characteristic Curves (TA=25°C unless otherwise noted)
Pulse Derating Curve
100
Peak Pulse Derating in Percentage
of Peak Power or Current (%)
80
60
40
20
0
0
25
50
75
100 125 150
T
A
-Ambient temperature(°C)
175
200
SOCAY Electronics Co., Ltd.
Revision September 25, 2013
www.socay.com
3/4
@ SOCAY Electronics Co., Ltd. 2013
Specifications are subject to change without notice.
Please refer to www.socay.com for current information.
Radial Lead Transient Voltage Suppressors (TVS)
KC Series
Dimensions
Dimensions
A
B
C
D
E
F
Inches
max 0.571
Max0.500
Φ0.051±0.004
0.236±0.040
0.950±0.028
max 0.10
Millimeters
max 14.5
max 12.7
Φ1.30±0.1
6.0±1.0
24.15±0.7
max 2.5
Part Numbering
Part Marking
KC -
×××
Socay Logo
KC - XXX
Product Type
Stand Off Voltage
Series
SOCAY Electronics Co., Ltd.
Revision September 25, 2013
www.socay.com
4/4
@ SOCAY Electronics Co., Ltd. 2013
Specifications are subject to change without notice.
Please refer to www.socay.com for current information.
