1600V 90A Rectifier Diode Module
RoHS Compliant
MIMMD90A160DK
PRODUCT FEATURES
·
·
·
·
·
·
Glass Passivated Chip
Aluminum Oxide Ceramic Isolated Metal Baseplate
Low Reverse Recovery Loss
Low Forward Voltage
High Surge Current Capability
Low Inductance Package
·
Field Supply For DC Motors
·
Line Rectifiers For Transistorized AC Motor Controllers
·
Non-controllable Rectifiers For AC/DC Converter
APPLICATIONS
ABSOLUTE MAXIMUM RATINGS
Symbol
V
RRM
I
F(AV)
I
F(RMS)
I
FSM
It
P
D
T
J
T
STG
V
isol
Weight
2
T
C
=25°C unless otherwise specified
Test Conditions
T
C
=85°C Rectangular, d=0.5
T
C
=85°C Rectangular, d=0.5
T
J
=45°C, t=10ms, 50Hz, Sine
T
J
=45°C,t=8.3ms, 60Hz, Sine
T
J
=45°C, t=10ms, 50Hz, Sine
T
J
=45°C,t=8.3ms, 60Hz, Sine
Max.
1600
90
130
2000
2200
20000
24200
347
-40 to +150
-40 to +125
AC, 50Hz, t=1min
3000
101
Unit
V
A
A
A
A
A
2
s
A
2
s
W
°C
°C
V
g
Parameter
Repetitive Reverse Voltage
Average Forward Current
RMS Forward Current
Non-Repetitive Surge
Forward Current
I t (For Fusing)
Power Dissipation
Junction Temperature
Storage Temperature Range
Insulation Test Voltage
2
ELECTRICAL AND THERMAL CHARACTERISTICS
Symbol
I
RM
V
F
R
θJC
Parameter
Reverse Leakage Current
Forward Voltage
Thermal Resistance
Test Conditions
V
R
=1600V
V
R
=1600V, T
J
=125°C
I
F
=200A
I
F
=200A,
T
J
=125°C
Junction-to-Case
T
C
=25°C unless otherwise specified
Min.
--
--
--
--
--
Typ.
--
--
1.33
1.3
--
Max.
200
5
1.5
--
0.36
Unit
µA
mA
V
V
°C /W
1600V 90A Rectifier Diode Module
RoHS Compliant
MIMMD90A160DK
MECHANICAL CHARACTERISTICS
Symbol
Torque
Torque
Parameter
Module-to-Sink
Module Electrodes
Test Conditions
Recommended（M6）
Recommended（M5）
Min.
3
2.5
Typ.
Max.
5
5
Unit
N· m
N· m
DA Package Outline (Dimensions in mm)
