Z8F043ASH020EG: DescriptionMicrocontroller, 8-Bit, FLASH, Z8 CPU, 20MHz, CMOS, PDSO20, SOIC-20; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，253 Pages; ManufacturerIXYS; Environmental Compliance

Download Datasheet Parametric Compare View All

Z8F043ASH020EG Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	Z8F043ASH020EG	-	-	View	Buy Now

Z8F043ASH020EG Overview

Microcontroller, 8-Bit, FLASH, Z8 CPU, 20MHz, CMOS, PDSO20, SOIC-20

Z8F043ASH020EG Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	IXYS
Parts packaging code	SOIC
package instruction	SOIC-20
Contacts	20
Reach Compliance Code	compliant
Has ADC	YES
Address bus width
bit size	8
CPU series	Z8
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G20
length	12.8 mm
Number of I/O lines	17
Number of terminals	20
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP20,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3/3.3 V
Certification status	Not Qualified
RAM (bytes)	256
rom(word)	4096
ROM programmability	FLASH
Maximum seat height	2.65 mm
speed	20 MHz
Maximum supply voltage	3.6 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.5 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Z8F043ASH020EG Preview

High-Performance 8-Bit Microcontrollers
