MBR0560-TP-HF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> MBR0560-TP-HF

MBR0560-TP-HF: DescriptionRectifier Diode, Schottky, 1 Element, 0.5A, 60V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size318KB，3 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

MBR0560-TP-HF Overview

Rectifier Diode, Schottky, 1 Element, 0.5A, 60V V(RRM), Silicon,

MBR0560-TP-HF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
package instruction	SOD-123, 2 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.7 V
JESD-30 code	R-PDSO-G2
Maximum non-repetitive peak forward current	5.5 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Maximum output current	0.5 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power dissipation	0.41 W
Maximum repetitive peak reverse voltage	60 V
Maximum reverse current	0.0001 µA
Reverse test voltage	60 V
surface mount	YES
technology	SCHOTTKY
Terminal form	GULL WING
Terminal location	DUAL

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736

Marilla

Street Chatsworth

!"#

$ % !"#

MBR0520

THRU

MBR0580

0.5 Amp

Schottky Rectifier

20 to

Volts

Features

Lead Free Finish/RoHS Compliant ("P" Suffix

designates RoHS Compliant. See ordering information)

For Surface Mount Application

Low Forward Voltage and Extremely Low Thermal Resistance

Halogen free available upon request by adding suffix "-HF"

Epoxy meets UL 94 V-0 flammability rating

Moisture Sensitivity Level 1

Maximum Ratings

Operating Temperature: -55 C to +150 C

Storage Temperature: -55 C to +150 C

Maximum Thermal Resistance:

244

C/W Junction to

Ambient

MCC

Catalog

Number

MBR0520

MBR0530

MBR0540

MBR0560

MBR0580

Maximum

Recurrent

Peak

Reverse

Voltage

20V

30V

40V

60V

80V

Maximum

RMS

Voltage

14V

21V

28V

42V

56V

Maximum

Blocking

Voltage

20V

30V

40V

60V

80V

SOD123

Device

Marking

Electrical Characteristics @ 25

C Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum

Instantaneous

F(AV)

FSM

0.5A

5.5A

=50 C

8.3ms half sine

DIM

Forward Voltage

MBR0520

MBR0530

MBR0540

MBR0560

MBR0580

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Typical Junction

Capacitance

Power dissipation

0.45V

0.55V

0.70V

0.80V

=0.5A

=25

DIMENSIONS

INCHES

MIN

MAX

MIN

MAX

.140

.152

3.55

3.85

.100

.112

2.55

2.85

.055

.071

1.40

1.80

-----

.053

-----

1.35

.012

.031

0.30

.78

.006

-----

0.15

-----

.01

-----

.25

-----

.006

-----

.15

SUGGESTED SOLDER

PAD LAYOUT

0.093"

NOTE

0.2mA

=25 C

Measured at

1.0MHz,

=4.0 V

0.048”

30pF

0.036”

410mW

Revision:

www.mccsemi.com

1 of 3

2013/01/01

MBR0560-TP-HF Related Products

	MBR0560-TP-HF	MBR0580-TP-HF	MBR0540-TP-HF	MBR0530-TP-HF
Description	Rectifier Diode, Schottky, 1 Element, 0.5A, 60V V(RRM), Silicon,	Rectifier Diode, Schottky, 1 Element, 0.5A, 80V V(RRM), Silicon,	Rectifier Diode, Schottky, 1 Element, 0.5A, 40V V(RRM), Silicon,	Rectifier Diode, Schottky, 1 Element, 0.5A, 30V V(RRM), Silicon,
Is it Rohs certified?	conform to	conform to	conform to	conform to
package instruction	SOD-123, 2 PIN	SOD-123, 2 PIN	R-PDSO-G2	SOD-123, 2 PIN
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	0.7 V	0.8 V	0.55 V	0.55 V
JESD-30 code	R-PDSO-G2	R-PDSO-G2	R-PDSO-G2	R-PDSO-G2
Maximum non-repetitive peak forward current	5.5 A	5.5 A	5.5 A	5.5 A
Number of components	1	1	1	1
Phase	1	1	1	1
Number of terminals	2	2	2	2
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
Maximum output current	0.5 A	0.5 A	0.5 A	0.5 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Maximum power dissipation	0.41 W	0.41 W	0.41 W	0.41 W
Maximum repetitive peak reverse voltage	60 V	80 V	40 V	30 V
Maximum reverse current	0.0001 µA	0.0001 µA	0.0001 µA	0.0001 µA
Reverse test voltage	60 V	80 V	40 V	30 V
surface mount	YES	YES	YES	YES
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL
Maker	Micro Commercial Components (MCC)	-	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)
