XDSL SPLITTER FILTER MODULE
B8802NL
SmartER series
POTS CO splitter for standard ADSL / VDSL2 applications
LPF compliant to ATIS specification TRQ.10.2009 Type A and
Type C for short loops (CO)
Part of a standard series which has footprint compatibility
For ADSL, ADSL2+, VDSL and VDSL2 applications
Compliant with Broadband Forum TR-127 standard for VDSL2
applications
Patented technology US7598837, US7598839, CN1667763,
EP1644943, TWI316724, CA2531599
Electrical Specifications @ 25°C
PARAMETER
POTS Impedance
POTS Insertion Loss
POTS Insertion Loss Dist ortion
relative to 1 kHz
POTS Return Loss
Longitudinal Balance
xDSL Insertion Loss
DC Current
Total DC Resistance
FREQUENCY
100 Hz to 4 kHz
1 kHz
200 Hz to 3.4 kHz
3.4 kHz to 4 kHz
200 Hz (SRL-L)
1 kHz (ERL)
2.2 kHz (SRL-H)
200 Hz to 3 kHz
25 kHz to 32 kHz
32 kHz to 12 MHz
12 MHz to 30 MHz
CO
900
Ω
0.75 dB MAX
0.5 dB to 1.5dB
1.0 dB to 1.5 dB
5 dB MIN
8 dB MIN
5 dB MIN
58 dB MIN
55 dB
65 dB
55 dB
100 mA MAX
25
Ω
MAX
CPE
600
Ω
0.6 dB MAX
0.5 dB to 1.5 dB
1.0 dB to 1.5 dB
5 dB MIN
8 dB MIN
5 dB MIN
58 dB MIN
55 dB
65 dB
55 dB
100 mA MAX
25
Ω
MAX
Mechanical
B8802NL
Weight
. . . . . . . . . . . 5.0 grams
Tray
. . . . . . . . . . . . . . . .80/tray
Inches
Dimensions:
mm
Unless otherwise specified, all
tolerances are ± .010
0,25
USA 858 674 8100
Germany 49 7032 7806 0
Singapore 65 6287 8998
Shanghai
86 21 62787060
China 86 755 33966678
Taiwan 886 3 4356768
www.pulseeng.com
1
B703.B (2/10)
XDSL SPLITTER FILTER MODULE
B8802NL
SmartER series
Schematic
B8802NL
2
xDSL
&
LINE
1
3
PHONE
4
For More Information:
Pulse Worldwide
Headquarters
Pulse Europe
Pulse China Headquarters Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yan An Rd. West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Zeppelinstrasse 15
12220 World Trade Dr. D-71083 Herrenberg
San Diego, CA 92128 Germany
U.S.A.
www.pulseeng.com
Tel: 858 674 8100
Fax: 858 674 8262
B402, Shenzhen Academy of
Aerospace Technology Bldg.
10th Kejinan Rd.
High-Tech Zone
Nanshan District
Shenzen, PR China 518057
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Fax: 49 7032 7806 135 Fax: 86 755 33966700
Pulse South
Asia
135 Joo Seng Rd.
#03-02
PM Industrial Bldg.
Singapore 368363
Tel: 65 6287 8998
Fax: 65 6287 8998
Pulse North Asia
3F, No. 198
Zhongyuan Rd.
Zhongli City
Taoyuan County 320
Taiwan R. O. C.
Tel: 886 3 4356768
Fax: 886 3 4356823
(Pulse)
Fax: 886 3 4356820
(FRE)
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners.
© Copyright, 2010. Pulse Engineering, Inc. All rights reserved.
