FJZ945
FJZ945
Audio Frequency Amplifier & High
Frequency OSC.
• Complement to FJZ733
• Collector-Base Voltage : V
CBO
=60V
• High Current Gain Bandwidth Product : f
T
=300MHz (Typ.)
1
3
2
SOT-623F
1. Base 2. Emitter 3. Collector
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
T
a
=25°C unless otherwise noted
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Power Dissipation
Junction Temperature
Storage Temperature
Parameter
Value
60
50
5
150
100
150
-55 ~ 150
Units
V
V
V
mA
mW
°C
°C
Electrical Characteristics
T
a
=25°C unless otherwise noted
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
h
FE
V
CE
(sat)
f
T
C
ob
NF
Parameter
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Collector-Emitter Saturation Voltage
Current Gain Bandwidth Product
Output Capacitance
Noise Figure
Test Condition
I
C
=100µA, I
E
=0
I
C
=10mA, I
B
=0
I
E
=10µA, I
C
=0
V
CB
=40V, I
E
=0
V
EB
=3V, I
C
=0
V
CE
=6V, I
C
=1.0mA
I
C
=100mA, I
B
=10mA
V
CE
=6V, I
C
=10mA
V
CB
=6V, I
E
=0, f=1MHz
V
CE
=6V, I
C
=0.5mA
f=1KHz, R
S
=500Ω
40
0.15
300
2.5
4.0
Min.
60
50
5
0.1
0.1
700
0.3
V
MHz
pF
dB
Typ.
Max.
Units
V
V
V
µA
µA
Thermal Characteristics
T
C
=25°C unless otherwise noted
Symbol
R
θJA
Parameter
Thermal Resistance, Junction to Ambient
Max.
1250
Units
°C/W
h
FE
Classification & Marking
Classification
h
FE
Marking
R
40 ~ 80
C2
O
70 ~ 140
C3
Marking
Y
120 ~ 240
C1
G
200 ~ 400
C4
L
350 ~ 700
C5
C1
©2003 Fairchild Semiconductor Corporation
Rev. B1, July 2003
FJZ945
Typical Characteristics
100
I
B
= 400
µ
A
I
C
[mA], COLLECTOR CURRENT
I
B
= 350
µ
A
80
100
V
CE
=6V
I
B
= 300
µ
A
I
B
= 250
µ
A
60
I
C
[mA], COLLECTOR CURRENT
80
0
0
I
B
= 200
µ
A
40
60
125 C
25 C
0
-25 C
I
B
= 150
µ
A
I
B
= 100
µ
A
40
20
I
B
= 50
µ
A
0
20
0
2
4
6
8
10
12
14
16
18
20
0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
V
BE
[V], BASE-EMITTER VOLTAGE
Figure 1. Static Characteristic
Figure 2. Transfer Characteristic
Ta=125 C
0
V
BE
(sat)[V], SATURATION VOLTAGE
V
CE
=6V
I
C
=10I
B
1
0
h
FE
, DC CURRENT GAIN
Ta=-25 C
Ta=25 C
100
0
Ta=-25 C
0
Ta=25 C
0
Ta=125 C
0
10
1
10
100
1000
0.1
1E-3
0.01
0.1
1
I
C
[mA], COLLECTOR CURRENT
I
C
[A], COLLECTOR CURRENT
Figure 3. DC Current Gain
Figure 4. Base-Emitter Saturation Voltage
1
100
I
C
=10I
B
V
CE
(sat)[V], SATURATION VOLTAGE
I
E
= 0
f = 1MHz
C
ob
[pF], CAPACITANCE
Ta=125 C
0
10
0.1
Ta=25 C
Ta=-25 C
0
0
1
0.01
1E-3
0.1
0.01
0.1
1
1
10
100
1000
I
C
[A], COLLECTOR CURRENT
V
CB
[V], COLLECTOR-BASE VOLTAGE
Figure 5. Collector-Emitter Saturation Voltage
Figure 6. Output Capacitance
©2003 Fairchild Semiconductor Corporation
Rev. B1, July 2003
