S1A - S1M
1.0AMP Surface Mount Rectifiers
SMA/DO-214AC
Features
For surface mounted application
Glass passivated chip junction
Low forward voltage drop
High current capability
Easy pick and place
High surge current capability
Plastic material used carries Underwriters
Laboratory Classification 94V-0
Meet MSL level 1, per J-STD-020,
LF maximum peak of 260℃
High temperature soldering:
260℃/10 seconds at terminals
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic
Terminal: Pure tin plated, lead free
solderable per J-STD-002B and
JESD22-B102D
Polarity: Indicated by cathode band
Packing: 12mm tape per EIA STD RS-481
Weight: 0.064 grams
Ordering Information (example)
Part No.
S1A
Package
SMA
Packing
1.8K / 7" REEL
Packing
code
R3
Packing code
(Green)
R3G
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Parameter
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
@1A
Maximum Reverse Current @ Rated VR
Typical Reverse Recovery Time (Note 2)
Typical Junction Capacitance (Note 3)
Non-Repetitive Peak Reverse Avalanche
Energy at 25℃, I
AS
=1A, L=10mH
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle
T
A
=25
℃
T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Trr
Cj
E
RSM
R
θjA
R
θjL
T
J
T
STG
S1A
50
35
50
S1B
100
70
100
S1D
200
140
200
S1G
400
280
400
1
40
1.1
1
50
1.5
12
5
S1J
600
420
600
S1K
800
560
800
S1M
1000
700
1000
Unit
V
V
V
A
30
A
V
uA
uS
pF
mJ
75
27
- 55 to + 175
- 55 to + 175
85
30
O
C/W
O
O
C
C
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Version:L13
RATINGS AND CHARACTERISTIC CURVES (S1A THRU S1M)
FIG.1 FORWARD CURRENT DERATING CURVE
100
AVERAGE FORWARD CURRENT (A)
1.2
1
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT (uA)
0.8
0.6
0.4
0.2
0
0
25
50
75
100
125
(
o
C)
10
RESISTIVE OR
INDUCTIVE LOAD
1
TA=125℃
150
175
0.1
TA=75℃
LEAD TEMPERATURE
PEAK FORWARD SURGE URRENT
(A)
100
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
8.3mS Single Half Sine Wave
JEDEC Method
S1A-S1K
0.01
TA=25℃
0.001
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
10
S1M
100
FIG. 5 TYPICAL FORWARD CHARACTERISTICS
TA=25℃
1
10
NUMBER OF CYCLES AT 60 Hz
100
INSTANTANEOUS FORWARD CURRENT (A)
1
100
FIG. 4 TYPICAL JUNCTION CAPACITANCE
10
CAPACITANCE (pF)
10
1
TA=25℃
Pulse Width=300us
1% Duty Cycle
TA=25℃
f=1.0MHz
1
0.01
0.1
1
REVERSE VOLTAGE (V)
10
100
0.1
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
FORWARD VOLTAGE (V)
Version:L13
