Datasheet
LambdaDriver® - Tunable Gain EDFA Optical Amplifier (EM800 - OABT/OAIT)
Features
Variable gain setting
Up to +24dBm output power
Extensive monitoring and alarms
Low noise figure
Power monitoring
Gain flatness
Wide input power range
Applications
Optical amplification with “in service” gain
control and adjustment
Optical Amplifier
The LambdaDriver
®
Optical Amplifier modules are a
family of EDFA (Erbium Doped Fiber Amplifier) devices
frequently used in DWDM Metro and Long-Haul
applications where optical signals amplification is
required in order to cover long span transmission.
The optical design, coupled with sophisticated control
circuitry, allows these Optical Amplifiers to operate in a
flexible and user configurable variable gain mode.
Accordingly, the same module can be used either as a
Booster OA or an In-Line OA making the WDM network
design an easier task. A significant advantage of this type
of OA is the capability to adjust the optical gain in a live
network without compromising gain flatness over the
entire C-band.
Gain settings can be done remotely via the Lambda
Driver management module and NMS platform.
Monitoring of input and output signal levels as well as
temperature and signal level alarms are provided.
Several models of Tunable Gain Optical amplifiers are
provided with optical output power ranging from
+17dBm to +24 dBm and also with integrated mid-stage
interface options for Dispersion Compensation Module
(DCM) insertion.
½½½½½
½½½½½
½½½½½
½½½½½½½½½½½
½½½½½½½½½½½
½½½½½½½½½½½
½½½½
½½½
½½½½½½½
½½ ½½½½
½½½
½½½
½½½½½½½½½½½
½½½½½
½½½½
½½½
½½½½½
½½½½½½½½½½½
½½½½½½½½½½½
½½ ½½
½½ ½½
½½½½½½½ ½½½½½½½½½
Long Haul Application
½½½½½½½ ½½½½½½½½½
½½½½½½½ ½½½½½½½½½
Not sure what solution best fits your needs? Visit www.mrv.com or e-mail us at sales@mrv.com
Environment Specifications
Operating Temperature
Storage Temperature
Relative Humidity
Dimensions (W x H x D)
EM800 Type
EM1600 Type
Weight
EM800 Type
EM1600 Type
Connectors
+ 17 dBm & 20 dBm Type
-5
o
C - 45
o
C
-10
o
C - 70
o
C
85% maximum, non-condensing
54.18 mm (2.13 in) x 130.7 mm (5.14 in) x 227 mm (8.956 in) (2 slot wide)
54.18 mm (2.13 in) x 263.4 mm (10.37 in) x 227 mm (8.956 in) (2 slot wide)
1.016 Kg (2.24Lb)
1.305 Kg (2.47Lb)
+24 dBm
Power consumption
+17 dBm & 20 dBm Type
+24 dBm
SC/UPC input and ouput
SC/UPC input , E2000APC output
10 Watt
20 Watt
Technical Specifications
Parameter
Wavelength Range
Maximum Output power
EM800/EM1600-OAIT17
EM800/EM1600-OAIT20
EM800/EM1600-OABT24
Input power Range
EM800/EM1600-OAIT17
EM800/EM1600-OAIT20
EM800/EM1600-OABT24
Input/Output Isolation (Min)
Signal Gain Range
EM800/EM1600-OAIT17
EM800/EM1600-OAIT20
EM800/EM1600-OABT24
Gain Flatness at Specified Gain with GFF
Noise Figure for Gain = 20 dB
Noise Figure for Gain = 15 dB
Optical Return Loss (at Input and Output ports)
Polarization Mode Dispersion
Polariziation Dependent Gain
Transient Overshoot (10 dB Drop)
Transient Suppression Time (10 dB Drop)
Minimum
1528
Value
Typical
Maximum
1563
+17
+20
+24
-23
-25
-16
30
12.5
10
7.5
+/-0.5
5.0
8.0
40
0.3
+/-0.2
0.5
0.5
+/-0.5
1.0
< 32
+3.5
+5
+10
Units
nm
dBm
dBm
dB
23.5
25
22.5
+/-1.0
5.5
9.0
dB
dB
dB
dB
dB
dB
dB
dB
µs
Management
LEDs
Monitoring
Alarm
EM800-OABT24
EM800-OABT24M
EM800-OAIT20
EM800-OAIT20M
EM800-OAIT17
EM800-OAIT17M
EM1600-OABT24
EM1600-OABT24M
EM1600-OAIT20
EM1600-OAIT20M
EM1600-OAIT17
EM1600-OAIT17M
Ordering Information
WDM transmission laser status, Temperature status, Port
reception status, Port transmission status
Input power, Output power, Gain, Temperature
Input power, Output power, Temperature
Optical Booster Amplifier with tunable gain for the Lambda Driver-800 with +24dbm output
Optical Booster with tunable gain and Mid Stage for the Lambda Driver-800 +24dbm output
Optical In Line Amplifier with tunable gain for the Lambda Driver-800 with +20dbm output
Optical In Line Amplifier with tunable gain and Mid Stage for the Lambda Driver-800 with +20dbm output
Optical In Line Amplifier with tunable gain for the Lambda Driver-800 with +17dbm output
Optical In Line Amplifier with tunable gain and Mid Stage for the Lambda Driver-800 with +17dbm output
Optical Booster Amplifier with tunable gain for the Lambda Driver-1600 with +24dbm output
Optical Booster with tunable gain and Mid Stage for the Lambda Driver-1600 +24dbm output
Optical In Line Amplifier with tunable gain for the Lambda Driver-1600 with +20dbm output
Optical In Line Amplifier with tunable gain and Mid Stage for the Lambda Driver-1600 with +20dbm output
Optical In Line Amplifier with tunable gain for the Lambda Driver-1600 with +17dbm output
Optical In Line Amplifier with tunable gain and Mid Stage for the Lambda Driver-1600 with +17dbm output
MRV-LD-OAT
Rev.1 03-09
Copyright ©2009 MRV Communications, Inc. All Rights Reserved.
