Optical Communications Systems™
Datasheet
Passive DWDM Components
Highlights
Passive MUX/DeMUX - 8, 16, or 32 channels
Passive Optical Add/Drop (OADM) - 1, 2, 4 or 8 channels
DWDM C-Band, 100GHz ITU Grid (0.8nm spacing)
Transparent operation - protocol and topology independent
Secure physical separation between data channels
Low insertion loss
Power required only for managed applications and LEDs
High port density
EM316DWMUX16
EM316DWMUX32
Overview
The Fiber Driver DWDM Passive MUX/DeMUX and OADM modules deliver the benefits of a Dense Wave Division Multiplexer in a fully
passive solution. With matching MUX/DeMUX units placed at each end of an optical link, up to 32 data channels can be combined
and transmitted over a single-mode fiber trunk. The passive OADM modules can add or drop up to 8 data channels at any point
along the trunk.
Because they operate independent of protocol and topology, these passive components remain transparent to both the network
and the end user. With plug-n-play setup and a design that minimizes budget loss, they can readily and seamlessly integrate into an
existing environment. Their small form factor and no power requirement means they can be placed virtually anywhere.
Contact your MRV Communications representative for additional information on Fiber Driver or any MRV product, including pricing
and availability.
Physical Specifications
Operating Temperature
Storage Temperature
Relative Humidity
Storage Humidity
Physical Dimensions:
One-Slot Module
Two-Slot Module
Approximate Weight:
One-Slot Module
Two-Slot Module
Regulatory Compliance
-5°C to 50°C (23°F to 122°F)
-55°C to 85°C (-67°F to 185°F)
85% maximum, non-condensing
5% to 95%, non-condensing
25 mm x 90 mm x 170 mm deep (1” x 3.56” x 6.67” deep)
50 mm x 90 mm x 170 mm deep (2” x 3.56” x 6.67” deep)
0.8 kg (1.8 lb)
1.4 kg (3.1 lb)
FCC Part 15 (Class A); IC (Class A); EMC Directive: Emission (Class A) and Immunity;
RoHS Directive; China RoHS; WEEE Directive
* If operated in a non-powered chassis, temp range is -5º C to 70º C (23º F to 158º F)
1
Optical Communications Systems™
Datasheet
PASSIVE DWDM MUX/DEMUX
Ordering Information
Max. Insertion
Loss (dB)
Max. Link
Insertion Loss
per Pair (dB)
Adjacent Ch.
Isolation (dB)
Non Adj. Ch.
Isolation (dB)
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
≥40
Wavelengths
Ports & Link
(nm)
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
100 GHz ITU Grid, C-Band
Description
Connectors
Ports/Link
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x8) / DMU (x2)
MU (x8) / DMU (x2)
MU (x8) / SC
MU (x8) / SC
MU (x8) / DMU (x2)
MU (x8) / DMU (x2)
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x8) / SC
MU (x16) / SC
MU (x16) / SC
MU (x16) / SC
MU (x16) / SC
MU (x16) / LC
MU (x16) / LC
MU (x32) / SC
MU (x32) / SC
MU (x32) / SC
MU (x32) / SC
Model
EM316DWMX8
EM316DWDMX8
EM316DWMX8-R1
EM316DWDMX8-R1
EM316DWMX8-R2
EM316DWDMX8-R2
EM316DWMX8-R2B
EM316DWDMX8-R2B
EM316DWMX8-B1
EM316DWDMX8-B1
EM316DWMX8-B2B
EM316DWDMX8-B2B
EM316DWMX8-CW3
EM316DWDMX8-CW3
EM316DWMX8-CW5
EM316DWDMX8-CW5
EM316DWMUX16-R
EM316DWDMX16-R
EM316DWMUX16-B
EM316DWDMX16-B
EM316DWMUX16-BE
EM316DWDMX16-BE
EM316DWMUX32
EM316DWDMX32
EM316DWMUX32-RB
EM316DWDMX32-RB
One Slot, passive 8-Ch. DWDM
MUX. Channels 31 - 38 (Red)
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 31 - 38 (Red)
One Slot, passive 8-Ch. DWDM
MUX. Channels 21 - 28 (Red)
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 21 - 28 (Red)
One Slot, passive 8-Ch. DWDM
MUX. Channels 29 - 36 (Red)
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 29 - 36 (Red)
One Slot, passive 8-Ch. DWDM MUX.
Channels 29 - 36 (Red) with band splitter.
One Slot, passive 8-Ch. DWDM DeMUX.
Channels 29 - 36 (Red) with band splitter.
One Slot, passive 8-Ch. DWDM
MUX. Channels 43 - 50 (Blue).
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 43 - 50 (Blue).
One Slot, passive 8-Ch. DWDM
MUX. Channels 51 - 58 (Blue).
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 51 - 58 (Blue).
One Slot, passive 8-Ch. DWDM
MUX. Channels 56 - 63 (Blue).
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 56 - 63 (Blue).
One Slot, passive 8-Ch. DWDM
MUX. Channels 31 - 38 (Red).
One Slot, passive 8-Ch. DWDM
DeMUX. Channels 31 - 38 (Red).
One Slot, passive 16-Ch. DWDM
MUX. Channels 21 - 36 (Red).
One Slot, passive 16-Ch. DWDM
DeMUX. Channels 21 - 36 (Red).
One Slot, passive 16-Ch. DWDM
MUX. Channels 43 - 58 (Blue).
One Slot, passive 16-Ch. DWDM
DeMUX. Channels 43 - 58 (Blue).
One Slot, passive 16-Ch. DWDM MUX.
Channels 43 - 58 (Blue) with Band splitter.
One Slot, passive 16-Ch. DWDM DeMUX.
Channels 43 - 58 (Blue) with Band splitter.
Two slot, passive 32-Ch. DWDM
MUX. Channels 21 - 52.
Two slot, passive 32-Ch. DWDM
DeMUX. Channels 21 - 52.
Two slot, passive 32-Ch. DWDM
MUX. Channels 21-36 & 43 - 58.
Two slot, passive 32-Ch. DWDM
DeMUX. Channels 21-36 & 43 - 58.
3.0
3.0
3.4
3.4
3.0
3.0
3.2
3.2
3.2
3.2
3.2
3.2
3.9
3.9
3.0
3.0
4.5
4.5
4.5
4.5
4.5
4.5
6.3
6.3
4.9
4.9
4.3
4.3
4.7
4.7
4.3
4.3
4.6
4.6
4.6
4.6
4.6
4.6
5.7
5.7
4.3
4.3
7
7
7
7
7
7
9.9
9.9
8.4
8.4
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
2
Optical Communications Systems™
Datasheet
PASSIVE DWDM OADM
Ordering Information
Max. Other
Chan. Insertion
Loss (dB)
Adjacent Ch.
Isolation (dB)
Non Adj. Ch.
Isolation (dB)
≥10
≥40
≥40
≥40
≥40
≥40
≥40
≥40
39
1546.12
40
1545.32
59
1530.33
60
1529.55
Trunk
Add/Drop
Wavelength
(nm)
Description
Data Port
Connector
Trunk
Connector
In/Out
Max.
Add/Drop
Insertion
1.5
1.8
2.4
3.6
1.5
2.0
1.3
2.0
Model
EM316DPADxx*
EM316DPADxxyy*
EM316DPAD4xx*
EM316DPAD8xx*
EM316DDADDxx*
EM316DDADDxxyy*
EM316DSADSxx*
EM316DSADSxxyy*
One slot, 1 channel passive
DWDM OADM.
One slot, 2 channel passive
DWDM OADM.
One slot, 4 channel passive
DWDM OADM.
One slot, 8 channel passive
DWDM OADM.
Dual Fiber, 1 channel
DWDM OADM.
Dual Fiber, 2 channel
DWDM OADM.
Single Fiber, 1 channel
DWDM OADM.
Single Fiber, 1 channel
DWDM OADM.
MU (x2)
MU (x4)
MU (x8)
MU (x16)
MU (x4)
MU (x8)
MU (x2)
MU (x2)
DLC/DLC
DLC/DLC
DLC/DLC
MU (x2) / MU (x2)
MU (x2) / MU (x2)
MU (x2) / MU (x2)
MU / MU
MU / MU
Select from 100 GHz ITU Grid,
C-Band channels 20-60
Select from 100 GHz ITU Grid,
C-Band channels 20-60
Select from 100 GHz ITU Grid,
C-Band channels 20-60
Select from 100 GHz ITU Grid,
C-Band channels 20-60
East/West (XX - Wavelength
from ITU Grid Table)
East/West (XXYY - Wavelength
from ITU Grid Table)
East/West (XX - Wavelength from
ITU Grid Table)
East/West (XXYY - Wavelength
from ITU Grid Table)
0.8
0.9
1.5
2.5
1.0
2.1
1.5
2.1
≥25
≥25
≥25
≥25
≥25
≥25
≥25
≥25
*See ITU Channel Table for
xx
and
yy
substitution values.
ITU CHANNEL TABLE
ITU Channel
(xx or yy)
Wavelength (nm)
21
1560.61
22
1559.79
23
1558.98
24
1558.17
25
1557.36
26
1556.56
27
1555.75
28
1554.94
29
1554.13
30
1553.33
31
1552.52
32
1551.72
33
1550.92
34
1550.12
35
1549.32
36
1548.52
37
1547.72
38
1546.92
ITU Channel
(xx or yy)
Wavelength (nm)
41
1544.53
42
1543.73
43
1542.94
44
1542.14
45
1541.35
46
1540.56
47
1539.77
48
1538.98
49
1538.19
50
1537.40
51
1536.61
52
1535.82
53
1535.04
54
1534.25
55
1533.47
56
1532.68
57
1531.90
58
1531.12
MRV has more than 50 offices throughout the world. Addresses, phone numbers and fax numbers are listed at www.mrv.com.
Please e-mail us at
info@mrv.com
or call us for assistance.
MRV Los Angeles
20415 Nordhoff Street
Chatsworth, CA 91311
800-338-5316
818-773-0900
MRV Boston
300 Apollo Drive
Chelmsford, MA 01824
800-338-5316
978-674-6800
MRV International
Business Park Moerfelden
Waldeckerstrasse 13
64546 Moerfelden-Walldorf
Germany
Tel. (49) 6105/2070
Fax (49) 6105/207-100
All statements, technical information and recommendations related to the products herein are based upon information believed to be reliable or accurate. However, the
accuracy or completeness thereof is not guaranteed, and no responsibility is assumed for any inaccuracies. Please contact MRV Communications for more information.
MRV Communications and the MRV Communications logo are trademarks of MRV Communications, Inc. Other trademarks are the property of their respective holders.
MRV-FD-DWDMMUX-102510
3020034-001 Rev. A2
Copyright ©2010 MRV Communications, Inc. All Rights Reserved.
