POWER FACTOR
CORRECTION INDUCTORS
P192 SERIES
•
•
•
•
•
•
•
PCB mounted PFC inductor with Aux winding
Ultra low audio noise design
Ultra low heat dissipation design
Switching Frequency: >45KHz
Input: 85Vac - 265Vac, 43Hz - 63Hz
Operating Temperature: -40°C to +100°C
RoHS compliant product
ELECTRICAL PARAMETERS @ 25°C
Part Number
P192-
501-2
401-3
301-4
601-2
501-3
401-4
301-5
L
(3-4) (Pri)
(μH ±10%)
500
400
300
600
500
400
300
Idc
(A)
Rdc
(3-4)
(Ω MAX)
0.20
0.20
0.20
0.20
0.15
0.15
0.15
Rdc
(9-10) (Aux)
(Ω MAX)
0.18
0.18
0.18
0.18
0.25
0.25
0.30
Turns Ratio
Pri:Aux
(±2%)
5:1
5:1
5:1
5:1
5:1
5:1
5:1
Dimension
2.5
3.0
4.0
2.5
3.0
4.0
5.5
A
A
A
B
B
B
B
Note:
1.
Inductance test @ 100KHz, 0.1Vrms
2.
Idc: 10% roll off max from initial inductance value
3.
Hipot: 1500Vrms, 5S, 1 mA, Pri to Aux
DIMENSIONS (mm)
DIMENSION A
DIMENSION B
SCHEMATIC
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ±0.015 .XXX : ±0.004
mm: X,X : ±0,38 X,XX : ±0,10
Tel: 310-325-1043
Fax: 310-325-1044
www.mpsind.com
