PULSE TRANSFORMER
R12703 SERIES
• RoHS Compliant Product
• Hipot : 500V
RMS
Primary to Secondary
• Turns Ratio : 1 : 1 ±2%
• Rise Time: 3.5 nS Max
• OCL, L
L
, C
WW
are measured @ 100KHz, 100mV
• Operating Temp : -40°C to +85°C
Industries
ELECTRICAL SPECIFICATION @ 25
O
C
PART NO.
R12703-
200
350
500
750
101
151
201
501
OCL
µH ±20%
20
35
50
75
100
150
200
500
L
L
µH Max
0.20
0.20
0.35
0.35
0.40
0.40
0.45
0.50
C
WW
pF Max
6
8
9
10
10
12
15
25
DCR
Ω Max
0.20
0.25
0.30
0.30
0.30
0.30
0.30
0.30
ET
V-µS Min
1.50
1.50
2.10
2.10
2.50
2.50
3.00
3.50
MECHANICAL
SCHEMATIC
Product performance is limited to specified parameters.
Data is subject to change without prior notice.
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ±0.015
.XXX : ±0.004
mm: X,X : ±0,38
X,XX : ±0,10
