8700 E. Thomas Road
Scottsdale, AZ 85252
Tel: (480) 941-6300
Fax: (480) 947-1503
USB0803C
thru
DESCRIPTION (500 watt)
This TRANSIENT VOLTAGE SUPPRESSOR (TVS) array is packaged
in an SO-8 configuration giving protection to 2 Bidirectional data or
interface lines. It is designed for use in applications where protection
is required at the board level from voltage transients caused by
electrostatic discharge (ESD) as defined in IEC 1000-4-2, electrical
fast transients (EFT) per IEC 1000-4-4 and effects of secondary
lighting.
USB0824C
TVSarray™ Series
™
These TVS arrays have a peak power rating of 500 watts for an
8/20µsec pulse. This array is suitable for protection of sensitive
circuitry consisting of TTL, CMOS DRAM’s, SRAM’s, HCMOS, HSIC
microprocessors,
UNIVERSAL SERIAL BUS (USB)
and I/O
transceivers. The USB08XXC product provides board level protection from static electricity and other
induced voltage surges that can damage or upset sensitive circuitry.
FEATURES
•
•
•
•
•
•
Protects up to 2 Bidirectional lines
Surge protection Per IEC 1000-4-2, IEC 1000-4-4
Provides electrically isolated protection
SO-8 Packaging
ULTRA LOW CAPACITANCE 5 pF per line pair
ULTRA LOW LEAKAGE
MECHANICAL
•
•
•
•
Molded SO-8 Surface Mount
Weight: 0.066 grams (approximate)
Marking: Logo, device number, date code
Pin #1 defined by DOT on top of package
MAXIMUM RATINGS
•
•
•
•
Operating Temperatures: -55 C to +150 C
Storage Temperature: -55
0
C to +150
0
C
Peak Pulse Power: 500 Watts (8/20
µsec,
Figure 1)
Pulse Repetition Rate: <.01%
0
0
PACKAGING
•
•
•
Tape & Reel EIA Standard 481-1-A
13 inch reel 2,500, pieces (OPTIONAL)
Carrier tubes 95 pcs per (STANDARD)
ELECTRICAL CHARACTERISTICS PER LINE @ 25
0
C Unless otherwise specified
STAND
OFF
VOLTAGE
V
WM
VOLTS
MAX
USB0803C
USB0805C
USB0812C
USB0815C
USB0824C
U3C
U5C
U12C
U15C
U24C
3.3
5.0
12.0
15.0
24.0
BREAKDOWN
VOLTAGE
V
BR
@1 mA
VOLTS
MIN
4
6.0
13.3
16.7
26.7
CLAMPING
VOLTAGE
V
C
@ 1 Amp
(FIGURE 2)
VOLTS
MAX
7
9.8
19
24
43
CLAMPING
VOLTAGE
V
C
@ 5 Amp
(FIGURE 2)
VOLTS
MAX
11
13
26
32
57
LEAKAGE
CURRENT
I
D
@ V
WM
µA
MAX
200
40
1
1
1
CAPACITANCE
(f=1 MHz)
@0V
C
pF
MAX
5
5
5
5
5
TEMPERATURE
COEFFICIENT
OF V
BR
á
VBR
mV/°C
MAX
-5
1
8
11
28
PART
NUMBER
DEVICE
MARKING
NOTE:
TVS product is normally selected based on its stand off Voltage V
WM
. Product selected voltage should be
equal to or greater than the continuous peak operating voltage of the circuit to be protected.
Application:
The USB08XXC product is designed for transient voltage suppression protection of ESD sensitive
components at the board level. It is an ideal product to be used for protection of I/O Transceivers.
MSC0323A.PDF
ISO 9001 CERTIFIED
REV N 7/07/2000
