YAGEO CORPORATION
ELECTROLYTIC CAPACITORS
SG
[ Electronic Ballast ]
105°C Single-Ended Lead Aluminum Electrolytic Capacitors
Miniature Aluminum
Electrolytic Capacitors
ELECTRICAL CHARACTERISTICS
Operating Temperature Range : -40 ~ +105°C / -25 ~ +105°C
Rated Voltage Range : 160 ~ 400V / 450V
Rated Capacitance Range : 4.7 ~ 330µF / 3.3~100µF
Capacitance Tolerance : -20 ~ +20% at 120Hz, 20°C
DC Leakage Current (µA): I = 0.06CV (µA) + 10µA whichever is greater.
(After Rated Voltage Applied for 2 Minutes)
Dissipation Factor
WV (V) : 160
D.F. (%) : 15
200
15
250
15
350
20
400
24
450
24
400
5
6
450
6
-
MULTIPLIER FOR RIPPLE CURRENT
Frequency Coefficient
FREQUENCY (Hz)
FREQUENCY (Hz)
50
1K
60
0.8
1.6
120
1.0
300
1.2
6.3~100V Below~68µF 0.8
6.3~100V Below~68µF 1.4
10K~100K
Low Temperature Stability Impedance Ratio (Max.)
W V (V) :
160
200
250
350
Z - 25°C / Z + 20°C
Z - 40°C / Z + 20°C
3
6
3
6
3
6
5
6
Endurance : After the rated voltage and rated ripple current have been applied at 105°Cfor 5000
hours, the capacitors shall meet the following requirements.
(a) Capacitance Change : Within 20% of Initial Value
(b) Dissipation Factor : 200% or Less of Initial Specified Value
(c) Leakage Current : Initial Specified Value or Less
Shelf Life : After having been placed at 105°C without voltage applied for 1000 hours, the capacitors
shall meet the same requirements as Endurance.
DIAGRAM OF DIMENSIONS
Dø
5.0
6.3
8.0
10.0
12.0
13.0
16.0
18.0
22.0
10.0
0.8 (1.0)
7.5
0.8
L
15Min.
5Min.
Dimensions: mm
Rubber Stand-off
F
2.0
2.5
3.5
5.0
dø
0.5
0.6
Vinyl Sleeve
(P.V.C)
Rubber End Seal
Vinyl Sleeve
(P.V.C)
F
±
0.5
D
±
0.5
L
Rubber End Seal
F
±
0.5
D
±
0.5
15Min.
5Min.
L
≤
16 L + 1.5Max.
L
>
16 L + 2Max.
Dø = 8 & 10 L + 2.5Max.
Dø
<
20 : Dø+0.5
Dø
≥
20 : Dø+1
46
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
160 (200)
SIZE
10
RIPPLE
200 (250)
SIZE
*10 x 15
RIPPLE
80
250 (300)
SIZE
*10 x 15
*10 x 19.5
15
22
10 x 19.5
160
*10 x 15
10 x 19.5
100
160
*10 x 25
13 x 20
33
10 x 19.5
210
*10 x 19.5
13 x 20
47
13 x 20
260
13 x 20
160
210
260
13 x 25
16 x 20
68
13 x 25
16 x 20
100
16 x 25
18 x 20
150
16 x 32
18 x 25
220
16 x 32
18 x 25
330
18 x 32
360
430
475
465
650
625
750
725
960
18 x 32
780
18 x 40
820
13 x 25
16 x 20
16 x 25
18 x 20
18 x 25
360
430
475
465
650
16 x 25
18 x 20
16 x 32
18 x 25
18 x 32
270
275
380
375
520
500
650
13 x 20
145
160
210
RIPPLE
85
100
D x L: mm
Note: 1. Ripple Current: (mA/rms) 105°C, 120Hz
2. *Down size: 3000 Hours
47
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
350 (400)
SIZE
3.3
4.7
6.8
10
10 x 19.5
100
*10 x 15
*10 x 15
10 x 19.5
60
72
100
RIPPLE
400 (450)
SIZE
RIPPLE
450 (500)
SIZE
10 x 19.5
13 x 20
*10 x 19.5
13 x 20
13 x 25
22
13 x 20
160
13 x 25
16 x 20
33
13 x 25
16 x 20
47
16 x 25
18 x 20
68
16 x 32
18 x 25
100
150
Note: 1. Ripple Current: (mA/rms) 105°C, 120Hz
2. *Down size: 3000 Hours
18 x 32
230
250
300
315
400
380
530
18 x 40
22 x 40
545
650
16 x 25
18 x 20
16 x 32
18 x 25
18 x 36
170
200
230
250
300
325
420
18 x 32
18 x 40
22 x 40
395
460
580
16 x 25
18 x 20
16 x 32
18 x 25
18 x 32
RIPPLE
60
80
90
110
110
190
200
275
280
340
D x L: mm
