BLM15AG700SH1: DescriptionFerrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN; CategoryAnalog mixed-signal IC filter; File Size84KB，3 Pages; ManufacturerMurata; Websitehttps://www.murata.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BLM15AG700SH1 Overview

Ferrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN

BLM15AG700SH1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Murata
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum DC resistance	0.15 Ω
filter type	FERRITE CHIP
high	0.5 mm
JESD-609 code	e3
length	1 mm
Manufacturer's serial number	BLM15A
Installation type	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output impedance	70 OHM Ω
physical size	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)
Rated current	0.5 A
Terminal surface	Tin (Sn)
width	0.5 mm

Preview

Download Datasheet

View All

Noise Suppression Products/EMI Suppression Filters > For Automotive > Chip Ferrite Bead for Automotive

Data Sheet

1

For Automotive

I

Dimensions

0.25±0.1

Chip Ferrite Bead for Automotive

BLM15A_SH Series (0402 Size)

I

Equivalent Circuit

1.0±0.05

0.5±0.05

(Resistance element becomes dominant

at high frequencies.)

: Electrode

(in mm)

I

Packaging

Code

D

J

B

Packaging

180mm Paper Tape

330mm Paper Tape

Bulk(Bag)

Minimum Quantity

10000

50000

1000

I

Rated Value (p: packaging code)

Part Number

BLM15AG100SH1p

BLM15AG700SH1p

BLM15AG121SH1p

BLM15AG221SH1p

BLM15AG601SH1p

BLM15AG102SH1p

Number of Circuits: 1

Continued on the following page.

Impedance

(at 100MHz/20°C)

10ohm (Typ.)

70ohm (Typ.)

120ohm

±25%

220ohm

±25%

600ohm

±25%

1000ohm

±25%

Impedance

(at 1GHz/20°C)

-

Rated Current

1000mA

500mA

300mA

200mA

DC Resistance

0.05ohm max.

0.15ohm max.

0.25ohm max.

0.35ohm max.

0.6ohm max.

1.0ohm max.

Operating

Temperature Range

-55 to +125°C

o

This data sheet is applied for CHIP FERRITE BEAD used for Automotive Electronics equipment for your design.

!

Note:

1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our

products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.

2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product

specifications or transact the approval sheet for product specifications before ordering.

2011.5.12

http://www.murata.com/

BLM15AG700SH1 Related Products

	BLM15AG700SH1	BLM15AG121SH1	BLM15AG102SH1	BLM15AG221SH1	BLM15AG601SH1	BLM15AG100SH1
Description	Ferrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN	Ferrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN	Ferrite Chip, 1 Function(s), 0.2A, EIA STD PACKAGE SIZE 0402, 2 PIN	Ferrite Chip, 1 Function(s), 0.3A, EIA STD PACKAGE SIZE 0402, 2 PIN	Ferrite Chip, 1 Function(s), 0.3A, EIA STD PACKAGE SIZE 0402, 2 PIN	Ferrite Chip, 1 Function(s), 1A, EIA STD PACKAGE SIZE 0402, 2 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum DC resistance	0.15 Ω	0.25 Ω	1 Ω	0.35 Ω	0.6 Ω	0.05 Ω
filter type	FERRITE CHIP	FERRITE CHIP	FERRITE CHIP	FERRITE CHIP	FERRITE CHIP	FERRITE CHIP
high	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm
JESD-609 code	e3	e3	e3	e3	e3	e3
length	1 mm	1 mm	1 mm	1 mm	1 mm	1 mm
Manufacturer's serial number	BLM15A	BLM15A	BLM15A	BLM15A	BLM15A	BLM15A
Installation type	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	1	1	1	1	1	1
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Output impedance	70 OHM Ω	120 OHM Ω	1000 OHM Ω	220 OHM Ω	600 OHM Ω	10 OHM Ω
physical size	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)	L1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)
Rated current	0.5 A	0.5 A	0.2 A	0.3 A	0.3 A	1 A
Terminal surface	Tin (Sn)	Tin (Sn)	Tin (Sn)	Tin (Sn)	Tin (Sn)	Tin (Sn)
width	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm
Base Number Matches	-	1	1	1	1	-
