Double Balanced Mixer
Multi-Octave Band
Electrical Specifications
(1)
Model MM9xMS
Model MM9xMS-14
RF 1.5 to 19.0 GHz
Specifications
Min
Typical
6.8 dB
7.8 dB
8.0 dB
23 dB
31 dB
25 dB
27 dB
20 dB
+5 dBm
+8 dBm
+12 dBm
+15 dBm
+14 dBm
+17 dBm
+21 dBm
+24 dBm
+10 dBm
+13 dBm
+17 dBm
+21 dBm
Max
9.0 dB
11.0 dB
11.5 dB
LO Power
4 = +10 dBm
6 = +13 dBm
7 = +17 dBm
8 = +21 dBm
:
Conditions
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
RF to IF:
IF to RF:
Input 1-dB
Compression Point:
RF(GHz)
2.0-18.0
2.0-18.0
1.5-19.0
LO(GHz)
2.0-18.0
2.0-18.0
1.5-19.0
1.5-4.0
4.0-19.0
1.5-19.0
1.5-19.0
1.5-19.0
1.5-19.0
0.5-6.5
0.5-6.5
IF(MHz)
2.0-5.0
0.5-6.5
0.5-6.5
17 dB
20 dB
20 dB
Input Third Order
Intercept Point:
1.5-19.0
1.5-19.0
0.5-.6.5
LO Power:
(4
)
1.5-19.0
1.5-19.0
0.5-6.5
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25˚C with the
nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss for IF frequencies greater than 10 MHz.
3. Conversion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
MM9xMS
Outline: MS3C
Typical
Performance
at 25˚C
MM9xMS-14
Outline: MS3D
All dimensions are in inches and [mm].
SP
