P6SMB180CALEADFREE datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> P6SMB180CALEADFREE

P6SMB180CALEADFREE: DescriptionTrans Voltage Suppressor Diode, 600W, 154V V(RWM), Bidirectional, 1 Element, Silicon, ROHS COMPLIANT, SMB, 2 PIN; CategoryDiscrete semiconductor diode; File Size834KB，3 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

P6SMB180CALEADFREE Overview

Trans Voltage Suppressor Diode, 600W, 154V V(RWM), Bidirectional, 1 Element, Silicon, ROHS COMPLIANT, SMB, 2 PIN

P6SMB180CALEADFREE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Central Semiconductor
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	UL RECOGNIZED
Maximum breakdown voltage	189 V
Minimum breakdown voltage	171 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-C2
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak reverse power dissipation	600 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	BIDIRECTIONAL
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	154 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Matte Tin (Sn)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	10

Preview

Download Datasheet

View All

P6SMB6.8CA

THRU

P6SMB250CA

SURFACE MOUNT

BI-DIRECTIONAL

GLASS PASSIVATED JUNCTION

SILICON TRANSIENT

VOLTAGE SUPPRESSOR

600 WATTS, 6.8 THRU 250 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR P6SMB6.8CA

Series types are Surface Mount Bi-Directional Glass

Passivated Junction Transient Voltage Suppressors

designed to protect voltage sensitive components from

high voltage transients.

THIS DEVICE IS MANUFACTURED WITH A GLASS

PASSIVATED CHIP FOR OPTIMUM RELIABILITY.

Note: For Uni-directional devices, please refer to the

P6SMB6.8A Series data sheet.

SMB CASE

• This series is UL listed, UL file number E130224

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SYMBOL

PPK

TJ, Tstg

UNITS

°C

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Peak Power Dissipation (Note 1)

Operating and Storage Junction Temperature

600

-65 to +150

ELECTRICAL CHARACTERISTICS:

(TA=25°C unless otherwise noted)

BREAKDOWN

VOLTAGE

TYPE

VBR @ IT

MIN

NOM

MAX

6.45

7.13

7.79

8.65

9.5

10.5

11.4

12.4

14.3

15.2

17.1

20.9

22.8

25.7

28.5

31.4

34.2

37.1

6.8

7.5

8.2

9.1

7.14

7.88

8.61

9.55

10.5

11.6

12.6

13.7

15.8

16.8

18.9

21.0

23.1

25.2

28.4

31.5

34.7

37.8

TEST

CURRENT

1.0

WORKING

PEAK

REVERSE

VOLTAGE

VRWM

5.8

6.4

7.02

7.78

8.55

9.4

10.2

11.1

12.8

13.6

15.3

17.1

18.8

20.5

23.1

25.6

28.2

30.8

33.3

MAXIMUM

REVERSE

LEAKAGE

CURRENT

IR @ VRWM

µA

2000

1000

400

100

5.0

MAXIMUM

CLAMPING

VOLTAGE

VC @ IPP

10.5

11.3

12.1

13.4

14.5

15.6

16.7

18.2

21.2

22.5

25.2

27.7

30.6

33.2

37.5

41.4

45.7

49.9

53.9

PEAK

PULSE

CURRENT

(Note 1)

IPP

14.4

13.2

11.2

MAXIMUM

TEMPERATURE

COEFFICIENT

ΘV

% / °C

0.057

0.061

0.065

0.068

0.073

0.075

0.078

0.081

0.084

0.086

0.088

0.090

0.092

0.094

0.096

0.097

0.098

0.099

0.100

C6V8C

C7V5C

C8V2C

C9V1C

C10C

C11C

C12C

C13C

C15C

C16C

C18C

C20C

C22C

C24C

C27C

C30C

C33C

C36C

C39C

MARKING

CODE

P6SMB6.8CA

P6SMB7.5CA

P6SMB8.2CA

P6SMB9.1CA

P6SMB10CA

P6SMB11CA

P6SMB12CA

P6SMB13CA

P6SMB15CA

P6SMB16CA

P6SMB18CA

P6SMB20CA

P6SMB22CA

P6SMB24CA

P6SMB27CA

P6SMB30CA

P6SMB33CA

P6SMB36CA

P6SMB39CA

Notes: (1) Non-repetitive 10x1,000µs pulse.
