AE235RAH12NGSN

Description
General Purpose Inductor, 0.012uH, 2%, 1 Element, Ceramic-Core, SMD, CHIP, 0402
CategoryPassive components    inductor
File Size207KB,2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Download Datasheet Parametric View All

AE235RAH12NGSN Overview

General Purpose Inductor, 0.012uH, 2%, 1 Element, Ceramic-Core, SMD, CHIP, 0402

AE235RAH12NGSN Parametric

Parameter NameAttribute value
MakerCOILCRAFT
Reach Compliance Codeunknown
ECCN codeEAR99
core materialCERAMIC
DC Resistance0.14 Ω
Nominal inductance(L)0.012 µH
Inductor ApplicationsPOWER INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
JESD-609 codee0
Manufacturer's serial numberAE235RAH
Number of functions1
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Maximum rated current0.75 A
self resonant frequency5500 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal surfaceTIN LEAD
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Tolerance2%
0402 CHIP INDUCTORS
Aerospace Grade Chip Inductors
AE235RAH
High SRF, excellent Q values and low DCR
20 inductance values from 1.5 nH to 56 nH
Comparable with other industry standards
Ideal for use in high-frequency telecommunications equipment
and in resonance circuits such as voltage-controlled oscillators.
Excellent current handling makes them perfect for power-
amplifier applications.
This robust version of Coilcraft’s standard 0402ME series
features high temperature materials that pass NASA low
outgassing specifications and allow operation in ambient
temperatures up to 155°C. The leach-resistant base
metalization with tin-lead (Sn-Pb) terminations ensures
the best possible board adhesion.
Part number
1
AE235RAH1N5JSZ
AE235RAH2N7JSZ
AE235RAH3N9JSZ
AE235RAH4N3JSZ
AE235RAH4N7JSZ
AE235RAH5N1JSZ
AE235RAH6N2GSZ
AE235RAH6N8GSZ
AE235RAH7N5GSZ
AE235RAH9N1GSZ
AE235RAH10NGSZ
AE235RAH12NGSZ
AE235RAH15NGSZ
AE235RAH18NGSZ
AE235RAH22NGSZ
AE235RAH27NGSZ
AE235RAH33NGSZ
AE235RAH39NGSZ
AE235RAH47NGSZ
AE235RAH56NGSZ
Inductance
2
(nH)
1.5
2.7
3.9
4.3
4.7
5.1
6.2
6.8
7.5
9.1
10
12
15
18
22
27
33
39
47
56
Percent
tolerance
5
5
5
5
5
5
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Q
3
nom
10
20
25
25
25
25
25
25
25
25
25
30
30
25
25
25
25
25
25
25
Q typ at
300 MHz
30
40
35
35
40
35
40
45
38
40
38
40
40
40
35
35
35
35
34
36
Q typ at
800 MHz
55
67
58
58
65
60
63
70
58
62
60
60
60
63
55
55
55
55
52
53
Q typ at
1.5 GHz
65
85
82
90
85
78
80
90
75
85
75
80
80
80
73
60
60
62
60
50
SRF min
4
(GHz)
18.0
15.0
10.0
10.0
8.0
8.0
8.0
6.0
6.0
5.5
5.5
5.5
5.0
4.5
4.0
3.5
3.2
3.0
2.9
2.8
DCR max
5
(Ohms)
0.03
0.05
0.07
0.07
0.07
0.12
0.09
0.09
0.13
0.14
0.17
0.14
0.16
0.27
0.30
0.52
0.63
0.70
1.08
1.17
Imax
(mA)
1500
1200
1000
1000
1000
800
950
950
850
800
750
750
700
500
500
400
380
350
270
210
1. When ordering, please specify
testing
code:
AE235RAH56NGSZ
Testing: Z
= Coilcraft Critical Products Environmental Stress
Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A screening
+ MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A screening
+ MIL-STD-981 Class S Group B qualification
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP
4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an AgilentHP 16193 test
fixture.
4. SRF measured using an Aglilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
5. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF840 test fixture.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Core material
Ceramic
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Paper tape: 8 mm wide, 0.68 mm thick, 2 mm pocket spacing
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document 434-1
Revised 06/02/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
