0402 CHIP INDUCTORS
Aerospace Grade Chip Inductors
AE235RAM
■
Higher inductance values than other 0402 inductors
■
Ferrite construction for high current handling
■
23 inductance values from 20 nH to 560 nH
This robust version of Coilcraft’s standard 0402AF series
features high temperature materials that pass NASA low
outgassing specifications and allow operation in ambient
temperatures up to 155°C. The leach-resistant base
metalization with tin-lead (Sn-Pb) terminations ensures the
best possible board adhesion.
Core material
Ferrite
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel. Paper
tape: 8 mm wide, 0.68 mm thick, 2 mm pocket spacing
Part number
1
Inductance
2
SRF typ
3
DCR max
4
Imax
±5% (nH)
(MHz)
(Ohms)
(mA)
20
22
33
36
39
51
56
72
78
100
140
180
200
220
250
270
300
330
360
390
420
470
560
2600
2500
2300
2300
2200
1930
1900
1650
1600
1400
1220
1150
1000
1150
900
860
860
820
810
760
700
650
600
0.050
0.065
0.060
0.075
0.115
0.070
0.095
0.100
0.130
0.160
0.260
0.280
0.440
0.530
0.360
0.550
0.410
0.560
0.575
0.750
0.700
0.730
0.920
1600
1300
1400
1300
830
1100
1000
1000
970
900
630
560
400
380
520
360
420
350
360
300
340
310
200
AE235RAM200JSZ
AE235RAM220JSZ
AE235RAM330JSZ
AE235RAM360JSZ
AE235RAM390JSZ
AE235RAM510JSZ
AE235RAM560JSZ
AE235RAM720JSZ
AE235RAM780JSZ
AE235RAM101JSZ
AE235RAM141JSZ
AE235RAM181JSZ
AE235RAM201JSZ
AE235RAM221JSZ
AE235RAM251JSZ
AE235RAM271JSZ
AE235RAM301JSZ
AE235RAM331JSZ
AE235RAM361JSZ
AE235RAM391JSZ
AE235RAM421JSZ
AE235RAM471JSZ
AE235RAM561JSZ
1. When ordering, please specify
testing
code:
AE235RAH56NGSZ
Testing: Z
= Coilcraft Critical Products Environmental Stress
Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A screening
+ MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A screening
+ MIL-STD-981 Class S Group B qualification
2. Inductance measured at 7.9 MHz using a Coilcraft SMD-F test fixture
and Coilcraft-provided correlation pieces with an Agilent/HP 4286
impedance analyzer.
3. SRF measured using Agilent/HP 8753D network analyzer and Coilcraft
SMD-D test fixture.
4. DCR measured on Cambridge Technology micro-ohmmeter and a
Coilcraft CCF858 test fixture.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
B
overall
E
A
E
D
terminal
C
F
G
H
F
Terminal wraparound:
approx 0.007/0,18 both ends
Suggested
Recommended
Land
Pattern
Land
Pattern
F
G
H
A max B max C max
0.044
1,12
0.026
0,66
D
E
0.026 0.020 0.009
0,66
0,51
0,23
0.017
0,43
0.018 0.026 inches
0,46
0,66 mm
All dimensions are without solder applied to the terminations. For
maximum dimensions with solder, add 0.006 inches / 0,152 mm.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE422-1
Revised 06/02/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
