PIN DIODE LIMITERS
PIN diode limiters are built to protect sensitive circuit elements such as receiver
front ends or detectors. They reduce high power inputs to a low level that can
be tolerated by the next component. Limiters may be categorized as
conventional or feedback types. The family of conventional limiters typically
exhibits leakage levels up to +20dBm with recovery times less than 40nsec.
These models handle up to 100W peak power levels and cover the frequency
range form 100MHz to 26GHz. Custom models with higher power handling are
available.
Features:
•
Low Insertion Loss
•
Low Leakage Power Circuit Protection
•
High CW Power Handling
•
Hermetically Sealed Modules
•
Assorted Package Styles
•
Custom Designs Available
Frequency
Range
(GHz)
0.1 - 1.1
0.5 - 2
0.1 - 4
1-4
2-4
0.5 - 6
2-8
0.5 - 8
1-8
4-8
2 - 12
8 - 12
0.5 - 18
2 – 18
8 - 18
18 - 26
Part
Number
ACLM4538
ACLM4530
ACLM4637
ACLM4581
ACLM4531
ACLM4700
ACLM4540
ACLM4606
ACLM4597
ACLM4532
ACLM4535
ACLM4533
ACLM4601
ACLM4537
ACLM4539
ACLM4765
Peak
Input
Power
(Watts) *(3)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
CW
Input
Power
(Watts) *(2,3)
2
2
2
2
2
2
2
2
2
2
2
2
1
1
1
1
Maximum
Flat Leakage
(Peak Power)
(+dBm)
20
20
20
20
20
20
20
20
20
20
21
21
21
21
21
23
Maximum
Flat Leakage
(CW Power)
(+dBm) *(1)
18
18
17
17
17
17
17
17
17
17
18
18
18
18
18
21
Maximum
Insertion
Loss
(dB)
0.4
0.4
0.5
0.5
0.5
0.7
0.7
0.8
0.8
0.8
1.5
1.5
1.8
1.8
1.8
2.5
Maximum
VSWR
1.4:1
1.4:1
1.4:1
1.4:1
1.4:1
1.5:1
1.5:1
1.5:1
1.5:1
1.5:1
1.6:1
1.6:1
1.9:1
1.9:1
1.9:1
2.0:1
Standard
Case
Styles
C3
C3
C3
C3
C3
C3
C3
C3
C3
C3
C3
C3
C36
C36
C36
C36
Optional
Case
Styles
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C36,C37,M22
C37,M22
C37,M22
C37,M22
M22
NOTES:
1) CW leakage is measured at 1W input.
2) Higher power handling available. Contact the factory to discuss specific requirements.
3) Power handling is linearly derated from full power at +25°C to zero power at +150°C.
611 Industrial Way West, Eatontown, NJ 07724
tel: 732-460-0212 fax: 732-460-0214
sales@advanced-control.com
www.advanced-control.com
ENVIRONMENTAL SPECIFICATIONS:
MIL-E-5400, MIL-STD-202, MIL-E-16400
Operating Temp: -65°C to +125°C
Storage Temp: -65°C to +150°C
Humidity: MIL-STD-202F, M103, Cond B
Shock: MIL-STD-202F, M213, Cond B
Altitude: MIL-STD-202F, M105, Cond B
Vibration : MIL-STD-202F, M204, Cond B
Thermal Shock: MIL-STD-202F, M107, Cond A
Temperature Cycle: MIL-STD-202F, M105C, Cond D
SCREENING :
Standard Screening:
Internal Visual per MIL-STD-883, Method 2017
Temperature Cycle: -65°C to +100°C, 10 cycles
Optional High-Rel Screening (Ref MIL-PRF-38534):
Internal Visual per MIL-STD-883, Method 2017
Stabilization Bake per MIL-STD-883, Method 1008
Temperature Cycle per MIL-STD-883, Method 1010
Constant Acceleration per MIL-STD-883, Method 2001
Burn-in per MIL-STD-883, Method 1015
Leak Test per MIL-STD-883, Method 1014
External Visual per MIL-STD-883, Method 2009
1.417
0.530
(REF.)
0.26
0.250
SMA MALE
(INPUT)
1.32±0.020
Ø0.312
0.07
0.48
0.625
SMA FEMALE
(OUTPUT)
SMA
MALE
INPUT
SMA
FEMALE
OUTPUT
Ø0.100±.005
THRU (2) PLCS.
CASE STYLE C3
CASE STYLE C36
1.282±0.010
0.525
(REF)
0.26
0.07
C
L
0.250
0.120
0.080
0.532
0.250
0.120
0.48
0.625
Ø0.012
TYP.
INPUT
0.246
±.003
OUTPUT
0.129
SMA
FEMALE
INPUT
SMA
FEMALE
OUTPUT
Ø0.100±0.005
THRU (2) PLCS.
0.058
TYP.
CASE STYLE C37
CASE STYLE M22
Part Number Ordering Information:
Example: ACLM4533C3R1K
ACLM4533: Conventional limiter, 8 – 12GHz
C3: Package type
R: Reversed connectors (omit for standard configuration)
1K: 1kW peak power handling (omit for standard 100W peak power handling)
LM-0205
611 Industrial Way West, Eatontown, NJ 07724
tel: 732-460-0212 fax: 732-460-0214
sales@advanced-control.com
www.advanced-control.com
