Frequency Doubler
Electrical Specifications
Parameter
Insertion Loss:
(2)
Fundamental Isolation:
(3)
Third Harmonic
Suppression:
(4)
Input VSWR:
Input Power:
(1)
High Isolation, In-line Output
:
Input 5 to 2800 MHz
Output 10 to 5600 MHz
Specifications
Min
25 dB
30 dB
25 dB
20 dBc
Typical
11.5 dB
12.3 dB
35 dB
40 dB
35 dB
33 dBc
1.5:1
1.7:1
1.5:1
+11 dBm
Max
13.0 dB
13.5 dB
Model FD34H-1
Conditions
Input (MHz)
5-2000
2000-2800
5-500
500-2000
2000-2800
5-2800
5-500
500-2000
2000-2800
5-2800
Output (MHz)
10-4000
4000-5600
10-1000
1000-4000
4800-5600
10-5600
10-1000
1000-4000
4800-5600
10-5600
Notes:
1. Specifications are guaranteed when tested as a doubler in a 50 Ohm system at +25˚C with nominal input
power. Specifications indicated as typical are not guaranteed.
2. Insertion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
3. Fundamental isolation is referenced to the fundamental input.
4. Third Harmonic Suppression is referenced to the second harmonic output.
FD34H-1
Outline: FPD1
Typical
Performance
at 25˚C
All dimensions are in inches and [mm].
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, FL 32905 · PH (888) 553-7531 · Fax (888) 553-7532
www.SpectrumMicrowave.com
Spectrum Microwave · 2707 Black Lake Place · Philadelphia, PA 19154 · PH (215) 464-4000 · Fax (215) 464-4001
Rev.
3/17/08
