FD34SM-1 Overview

High Isolation, In-line Output

FD34SM-1 Parametric

Parameter Name	Attribute value
Maker	API Technologies
package instruction	MODULE,4LEAD,.5SQ
Reach Compliance Code	compli
Number of terminals	4
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	MODULE,4LEAD,.5SQ
RF/Microwave Device Types	FREQUENCY DOUBLER

Preview

Download Datasheet

View All

Frequency Doubler

High Isolation, In-line Output

Electrical Specifications :

Parameter

Insertion Loss:

(2)

Fundamental Isolation:

(3)

Third Harmonic

Suppression:

(4)

Input VSWR:

Input Power:

(1)

Model FD34SM-1

Input 5 to 2800 MHz

Output 10 to 5600 MHz

Conditions

Input (MHz)

5-2000

2000-2800

5-500

500-2000

2000-2800

5-2800

5-500

500-2000

2000-2800

5-2800

Output (MHz)

10-4000

4000-5600

10-1000

1000-4000

4000-5600

10-5600

10-1000

1000-4000

4000-5600

10-5600

Min

Specifications

Typical

11.5 dB

12.3 dB

35 dB

40 dB

35 dB

33 dBc

1.5:1

1.7:1

1.5:1

+11 dBm

Max

13.0 dB

14.0 dB

25 dB

30 dB

25 dB

20 dBc

Notes:

1. Specifications are guaranteed when tested as a doubler in a 50 Ohm system at +25˚C with nominal input

power. Specifications indicated as typical are not guaranteed.

2. Insertion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.

3. Fundamental isolation is referenced to the fundamental input.

4. Third Harmonic Suppression is referenced to the second harmonic output.

FD34SM-1

Outline: SMD1

Typical

Performance

at 25˚C

SMI

All dimensions are in inches and [mm].

Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, FL 32905 · PH (888) 553-7531 · Fax (888) 553-7532

www.SpectrumMicrowave.com

Spectrum Microwave · 2707 Black Lake Place · Philadelphia, PA 19154 · PH (215) 464-4000 · Fax (215) 464-4001

REV A

8/6/10
