Frequency Doubler
Electrical Specifications
(1)
:
Model FD9xMS-1
Input 1.5 to 10.0 GHz
Output 3.0 to 20.0 GHz
Model FD9xMS-1
High Isolation, In-line Output
Conditions
Parameter
Insertion Loss:
(2)
Fundamental
Isolation:
(3)
Third Harmonic
Suppression:
(4)
Input VSWR:
Input Power:
Input (GHz)
2.0-9.0
1.5-10.0
2.0-10.0
2.0-7.0
1.5-5.0
5.0-10.0
1.5-10.0
Output (GHz)
4.0-18.0
3.0-20.0
2.0-10.0
6.0-21.0
3.0-10.0
10.0-20.0
3.0-20.0
Min
Specifications
Typical
11.0 dB
11.5 dB
33 dB
33 dBc
2.2:1
1.75:1
+11 dBm
+17 dBm
Max
13.0 dB
15.0 dB
25 dB
20 dBc
Input Power
6 = +11 dBm
7 = +17 dBm
FD96
FD97
Notes:
1. Specifications are guaranteed when tested as a doubler in a 50 Ohm system at +25
˚
C with nominal input power.
Specifications indicated as typical are not guaranteed.
2. Insertion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
3. Fundamental isolation is referenced to the fundamental input.
4. Third Harmonic Suppression is referenced to the second harmonic output.
Typical
Performance
at 25˚C
FD9xMS-1
Outline: MSD1
All dimensions are in inches and [mm].
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, FL 32905 · PH (888) 553-7531 · Fax (888) 553-7532
www.SpectrumMicrowave.com
Spectrum Microwave · 2707 Black Lake Place · Philadelphia, PA 19154 · PH (215) 464-4000 · Fax (215) 464-4001
REV. A
7/13/09
