Frequency Doubler
Electrical Specifications
(1)
:
Model FD9xSMx-1
Input 2.0 to 10.0 GHz
Output 4.0 to 20.0 GHz
Model FD9xSMx-1
Max
13.0 dB
15.0 dB
High Isolation, In-line Output
Conditions
Parameter
Insertion Loss:
(2)
Fundamental Isolation:
Third Harmonic
Suppression:
(4)
Input VSWR:
Input Power:
(3)
Specifications
Min
25 dB
20 dBc
Typical
11.0 dB
11.5 dB
32 dB
26 dBc
2.5:1
1.8:1
+11 dBm
+17 dBm
Input (GHz)
2.0-9.0
2.0-10.0
2.0-10.0
2.0-10.0
2.0-5.0
5.0-10.0
2.0-10.0
Output (GHz)
4.0-18.0
4.0-20.0
4.0-10.0
4.0-20.0
4.0-10.0
10.0-20.0
4.0-20.0
Input Power
6 = +11 dBm
7 = +17 dBm
D = No Cover
H = With Cover
FD96
FD97
Notes:
1. Specifications are guaranteed when tested as a doubler in a 50 Ohm system at +25˚C with nominal input
power. Specifications indicated as typical are not guaranteed.
2. Insertion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
3. Fundamental isolation is referenced to the fundamental input.
4. Third Harmonic Suppression is referenced to the second harmonic output.
FD9xSMD-1
Outline: SMDD3
Typical
Performance
at 25˚C
FD9xSMH-1
Outline: SMDH3
All dimensions are in inches and [mm].
Spectrum Microwave ·2144 Franklin Drive N.E. · Palm Bay, FL 32905 · PH (888) 553-7531 · Fax (888) 553-7532
www.SpectrumMicrowave.com
Spectrum Microwave· 2707 Black Lake Place · Philadelphia, PA 19154 · PH (215) 464-4000 · Fax (215) 464-4001
Rev.
3/17/08
