FREQUENCY DOUBLER
MODEL
FD9xxN-1
Features
Input Power: +11 dBm
Operating Temperature: -55 ºC to +85ºC
Available as:
FD9xxN-1, Connectorized Housing (ND)
FD9xMN-1, Without Connectors
FD9xPN-1, With Removable Connectors
RF Input: 1.5 to 10.0 GHz
RF Output: 3.0 to 20.0 GHz
Conditions
Specifications
Typical
11.0 dB
12.0 dB
30 dB
25 dB
33 dBc
2.0:1
1.5:1
+11 dBm
+17 dBm
Electrical Speci cations
(1)
:
Insertion Loss:
Parameter
(2)
Input (GHz)
2.5 - 9.0
1.5 - 10.0
1.5 - 7.0
7.0 - 10.0
1.5 - 10.0
1.5 - 5.0
5.0 - 10.0
1.5 - 10.0
Output (GHz)
5.0 - 18.0
3.0 - 20.0
1.5 - 7.0
7.0 - 10.0
3.0 - 20.0
3.0 - 10.0
10.0 - 20.0
3.0 - 10.0
Min
22 dB
19 dB
20 dBc
Max
12.5 dB
14.0 dB
Fundamental Isolation:
(3)
Third Harmonic
Suppression:
(4)
Input VSWR:
Input Power Range:
Notes:
FD96
FD97
1. Speci cations are guaranteed when tested as a doubler in a 50 Ohm system at +25ºC with the nominal input power.
Speci cations indicated as typical are not guaranteed.
2. Insertion loss typically degrades less than 0.5 dB at +100ºC
and improves less than 0.5 dB at
-55º C.
3. Fundamental isolation is referenced to the fundamental input.
4. Third Harmonic Suppression is referenced to the second harmonic output.
Case Outline
(FD9xxN-1)
All dimensions are in inches and [mm].
9
10
11
12
13
1.0
1.5
2.0
3.0
4.0
10
1.5
3.0
Typical
Performance
at
25ºC
Insertion Loss (dB)
0
0.5
1.0
1.5
2.0
10
20
30
40
Relative Loss vs. Input Power (dB)
6 GHz
Input
-5 dB
NOM.
+5 dB
Fundamental Isolation (dB)
In-GHz
Out-GHz
10.0
20.0
50
0
0.5
1.0
1.5
1.5
In-GHz
10.0
Output VSWR
Relative Loss vs. Input Power (dB)
2 GHz
Input
Third Harmonic Suppression (dBc)
3.0
GHz
20.0
2.0
1.0
1.5
2.0
3.0
-5 dB
NOM.
+5 dB
Input VSWR
20
30
40
50
1.5
4.5
In-GHz
Out-GHz
7.0
21.0
4.0
1.5
GHz
10.0
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, FL 32905 · PH (888) 553-7531 · Fax (888) 553-7532
12/21/05
www.SpectrumMicrowave.com
Spectrum Microwave (Europe) · 2707 Black Lake Place · Philadelphia, PA 19154 · PH (215) 464-4000 · Fax (215) 464-4001
