RF AMPLIFIER
MODEL
TM9129
Features
!
High Output Power: +20 dBm Typical
!
Environmental Screening Available
!
Operating Temp. -55 ºC to +85 ºC
Available as:
TM9129, 4 Pin TO-8 (T4)
TN9129, 4 Pin Surface Mount (SM3)
FP9129, 4 Pin Flatpack (FP4)
BX9129, Connectrized Housing (H1)
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point........+48 dBm (Typ.)
Second Order Two Tone Intercept Point.........+42 dBm (Typ.)
Third Order Two Tone Intercept Point.............+34 dBm (Typ.)
Specifications
CHARACTERISTIC
Frequency
Gain (dB)
Power @ 1 dB
Comp. (dBm)
Reverse
Isolation (dB)
VSWR
In
Out
TYPICAL
Ta= 25 ºC
10-1500 MHz
8
+20
-15
<1.5:1
<1.5:1
<8
+15
95
MIN/MAX
Ta = -55 ºC to +85 ºC
10-1500 MHz
6.0 Min.
+19 Min.
-13.0 Min.
2.0:1 Max.
2.0:1 Max.
9.5* Max.
+15
100 Max.
Maximum Ratings
Ambient Operating Temperature .............. -55ºC to + 100 ºC
Storage Temperature ............................... -62ºC to + 125 ºC
Case Temperature ................................................. + 125 ºC
DC Voltage ......................................................... + 18 Volts
Continuous RF Input Power ................................. + 18 dBm
Short Term RF Input Power .... 200 Milliwatts (1 Minute Max.)
Maximum Peak Power .................... 0.5 Watt (3
µsec
Max.)
Noise Figure (dB)
Power
Vdc
mA
Note: Care should always be taken to effectively ground the case of each unit.
* Noise Figure will be Greater Below 40 MHz
Typical Performance Data
0
10
9
8
7
6
Start 10 MHz
Gain (dB)
Reverse Isolation (dB)
10
8
6
4
2
Start 10 MHz
Stop 1500 MHz
Start 40 MHz
Noise Figure (dB)
- 10
- 20
- 30
- 40
Stop 1500 MHz
Stop 1500 MHz
1 dB Comp. (dBm)
+23
+22
+21
+20
+19
Start 10 MHz
Stop 1500 MHz
2.0
1.5
1.0
Start 10 MHz
Input VSWR
2.0
1.5
1.0
Stop 1500 MHz
Start 10 MHz
Output VSWR
Stop 1500 MHz
Legend
+ 25 ºC
+ 85 ºC - - - - - - -55 ºC
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532
08/05/04
www.spectrummicrowave.com
Spectrum Microwave (Europe) · 2707 Black Lake Place · Philadelphia, Pa. 19154 · PH (215) 464-4000 · Fax (215) 464-4001
