OSCILLATOR SPECIFICATIONS
22SMODO
DATE
Apr. 6, 2009
1. Part No. :
2. Nominal frequency :
3. Frequency stability :
4. Operating Conditions
Operating temperature :
Output 1: 1.0000 MHz to 52.0000 MHz (blank frequency)
Output 2: 13.0000 MHz to 52.0000 MHz (1/1 or 1/2 divided frequency)
±25ppm, ±30ppm, ±50 ppm or ±100ppm over all conditions
-20°C to +75°C
-40°C to +85°C (W)
-55°C to +100°C
+1.8V to +3.3V DC ±10%
4 mA, typ. at f = 27 MHz, V
DD
=+3.3V, CL=15pF
40% to 60% at 1/2 V
DD
level
10 ns max. (10%V
DD
to 90%V
DD
level)
10%V
DD
max.(V
oL
)
90%V
DD
min.(V
oH
)
CMOS 15pF max.
10 ms max.
±5 ppm max. at +25°C ±3K for first year
+250°C ±10K for 10 seconds (reflow soldering)
+170°C ±10K for 1 to 2 minutes (preheating)
See below
2.5±0.1
#4
#3
2.0±0.1
PIN
1
2
3
4
CONNECTION
Storage temperature :
Input voltage (V
DD
) :
5. Input current :
6. Output (-20°C to +75°C)
Symmetry :
Rise and fall times :
"0" level :
"1" level :
Output load :
7. Start-up time :
8. Aging :
9. Reflow soldering condition :
10. Outline dimensions :
22SMODO
RoHS compliant (Pb-FREE)
OUTPUT 2
GND
OUTPUT 1
V
DD
#1
#2
0.8
#1
0.9
0.8
#2
0.7 0.6 0.7
#4
#3
0.9max.
mm
ISSUED
CHECKED
APPROVAL
SM I
'
09/04/06
SM I
'
09/04/06
SM I
'
09/04/06
ITEM.
DUAL OUTPUT
CRYSTAL CLOCK OSCILLATORS
No.
SO-9936C
