RF AMPLIFIER
MODEL
TM9321
Features
!
!
!
!
High Gain: 23 dB Gain Typical
Output Power: +14 dBm Typical
Operating Temp. - 55 ºC to +85 ºC
Environmental Screening Available
Available as:
TM9321, 4 Pin TO-8 (T4)
TN9321, 4 Pin Surface Mount (SM3)
FP9321, 4 Pin Flatpack (FP4)
BX9321, Connectorized Housing (H1)
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point ....... +51 dBm (Typ.)
Second Order Two Tone Intercept Point ........ +45 dBm (Typ.)
Third Order Two Tone Intercept Point ............ +27 dBm (Typ.)
Specifications
CHARACTERISTIC
Frequency
Gain (dB)
Power @ 1 dB
Comp. (dBm)
Reverse
Isolation (dB)
In
Out
Noise figure (dB)
Power
Vdc
mA
VSWR
TYPICAL
Ta= 25 ºC
5 - 1000 MHz
23
+14
-32
<1.6:1
<1.6:1
<4.2
+15
64
MIN/MAX
Ta = -55 ºC to +85 ºC
5 - 1000 MHz
21.0 Min.
+12.0 Min.
-30
Max.
Maximum Ratings
Ambient Operating Temperature .............. -55ºC to + 100 ºC
Storage Temperature ............................... -62ºC to + 125 ºC
Case Temperature ................................................. + 125 ºC
DC Voltage ......................................................... + 18 Volts
Continuous RF Input Power ................................. + 13 dBm
Short Term RF Input Power ...... 50 Milliwatts (1 Minute Max.)
Maximum Peak Power .................... 0.5 Watt (3
µsec
Max.)
2.0:1 Max.
2.0:1 Max.
5.0 Max.
+15
70
Max.
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
Gain (dB)
25
24
23
22
21
Start 5 MHz
Stop 1000 MHz
0
- 10
- 20
- 30
- 40
Reverse Isolation (dB)
6
5
4
3
2
Start 5 MHz
Stop 1000 MHz
Start 5 MHz
Noise Figure (dB)
Stop 1000 MHz
1 dB Comp. (dBm)
+17
+16
+15
+14
+13
Start 5 MHz
Stop 1000 MHz
2.0
1.5
1.0
Start 5 MHz
Input VSWR
2.0
1.5
1.0
Stop 1000 MHz
Start 5 MHz
Output VSWR
Stop 1000 MHz
Legend
+ 25 ºC
+ 85 ºC - - - - - - -55 ºC
Linear S-Parameters
– – – – S21– – – –
– – – – S12– – – –
FREQ.
– – – – S11– – – –
– – – – S22– – – –
Mag
MHz
Mag
Deg
Mag
Deg
Mag
Deg
Deg
======================================================================================
5
10
50
100
200
400
600
800
1000
.06
.02
.01
.02
.04
.09
.13
.16
.15
112
101
-129
-133
-143
174
130
81
25
14.17
14.38
14.26
14.25
14.28
14.38
14.51
14.44
14.11
19
7
-10
-21
-44
-90
-136
176
126
.02
.02
.02
.02
.02
.02
.02
.03
.02
23
11
2
1
3
-1
-4
-11
-22
.23
.12
.05
.05
.06
.09
.08
.04
.07
122
124
162
-179
-160
-170
174
168
-137
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532
11/22/04
www.spectrummicrowave.com
Spectrum Microwave (Europe) · 2707 Black Lake Place · Philadelphia, Pa. 19154 · PH (215) 464-4000 · Fax (215) 464-4001
