Finisar
Product Specification
1.25 Gb/s RoHS Compliant Long-Wavelength
Pluggable SFP Transceiver
FTLF1318P2xTL
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
•
Up to 1.25Gb/s bi-directional
data links
Hot-pluggable SFP footprint
Build-in digital diagnostic
functions
1310nm Fabry-Perot laser
transmitter
Duplex LC connector
RoHS compliant and Lead Free
Up to 10 km on 9/125μm SMF
Metal enclosure for lower EMI
Single 3.3V power supply
Low power dissipation <600mW
typical
Industrial operating temperature
range: -40°C to 85°C
APPLICATIONS
•
•
1.25Gb/s 1000Base-LX Ethernet
1.06 Gb/s Fibre Channel
Finisar’s FTLF1318P2xTL Small Form Factor Pluggable (SFP) transceivers are
compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)
4
.
They simultaneously comply with Gigabit Ethernet as specified in IEEE Std 802.3
1
and
1x Fibre Channel as defined in FC-PI-2 Rev. 10.0
3
. They are RoHS compliant and lead-
free per Directive 2002/95/EC
5
and Finisar Appl. Note AN-2038. Digital diagnostics
functions are available via the 2-wire serial bus specified in the SFP MSA.
PRODUCT SELECTION
FTLF1318P2xTL
x
W
B
Wide Extraction Bail
Narrow Extraction Bail
Page 1
©
Finisar Corporation April 12, 2007 Rev. A1
FTLF1318P2xTL SFP Product Specification – April 2007
Finisar
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
Rate Select
LOS
V
EER
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault.
Transmitter Disable. Laser output disabled on high or open.
Module Definition 2. Data line for Serial ID.
Module Definition 1. Clock line for Serial ID.
Module Definition 0. Grounded within the module.
No connection required
Loss of Signal indication. Logic 0 indicates normal operation.
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled
Receiver Non-inverted DATA out. AC Coupled
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
4
4
4
5
6
1
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. T
FAULT
is an open collector/drain output, which should be pulled up with a 4.7k – 10k Ohms resistor on
the host board if intended for use. Pull up voltage should be between 2.0V to Vcc + 0.3V. A high
output indicates a transmitter fault caused by either the TX bias current or the TX output power
exceeding the preset alarm thresholds. A low output indicates normal operation. In the low state, the
output is pulled to <0.8V.
3. Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
4. Should be pulled up with 4.7k - 10 kohms on host board to a voltage between 2.0V and 3.6V.
MOD_DEF(0) pulls line low to indicate module is plugged in.
5. Finisar FTLF1318xxxxx transceivers operate at 1x Fibre Channel and Gigabit Ethernet data rates and
respective protocols without active control.
6. LOS is open collector output. Should be pulled up with 4.7k – 10 kohms on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
©
Finisar Corporation April 12, 2007 Rev. A1
Page 2
FTLF1318P2xTL SFP Product Specification – April 2007
Finisar
VeeT
1
2
3
4
VeeT
TD-
TXFault
TD+
TX Disable
VeeT
MOD-DEF(2)
VccT
20
19
18
17
16
15
14
13
12
11
Towards
Bezel
5
6
7
8
9
10
MOD-DEF(1)
VccR
MOD-DEF(0)
VeeR
Rate Select
RD+
LOS
RD-
VeeR
VeeR
VeeR
Towards
ASIC
Pinout of Connector Block on Host Board
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Symbol
Vcc
T
S
T
OP
RH
Min
-0.5
-40
-40
0
Typ
Max
4.0
100
85
85
Unit
V
°C
°C
%
Ref.
1
III.
Electrical Characteristics
(T
OP
= -40 to 85
°C,
V
CC
= 3.00 to 3.60 Volts)
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Min
3.00
Typ
175
100
250
Vcc – 1.3
Vee
1200
Vcc
Vee+ 0.8
10
400
800
300
300
Vcc
HOST
Vee+0.5
80
122.4
Max
3.60
300
Unit
V
mA
Ω
mV
V
V
us
mV
ps
ps
V
V
mVpp
ps
ps
Ref.
Parameter
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Single ended data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Transmit Disable Assert Time
Receiver
Single ended data output swing
Data output rise time
Data output fall time
LOS Fault
LOS Normal
Power Supply Rejection
Deterministic Jitter Contribution
Total Jitter Contribution
2
3
Vout,pp
t
r
t
f
V
LOS fault
V
LOS norm
PSR
RX
Δ
DJ
RX
Δ
TJ
300
Vcc – 0.5
Vee
100
4
5
5
6
6
7
8
©
Finisar Corporation April 12, 2007 Rev. A1
Page 3
FTLF1318P2xTL SFP Product Specification – April 2007
Finisar
Notes:
1. Non-condensing.
2. AC coupled.
3. Or open circuit.
4. Into 100 ohm differential termination.
5. 20 – 80 %
6. LOS is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
7. All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5
MHz up to specified value applied through the power supply filtering network shown on page 23 of the
Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA), September 14, 2000.
8. Measured with DJ-free data input signal. In actual application, output DJ will be the sum of input DJ
and
Δ
DJ.
IV. Optical Characteristics (T
OP
= -40 to 85
°C,
V
CC
= 3.00 to 3.60 Volts)
Parameter
Transmitter
Output Opt. Power
Optical Wavelength
Spectral Width
Optical Modulation Amplitude
Optical Rise/Fall Time
RIN
Deterministic Jitter Contribution
Total Jitter Contribution
Optical Extinction Ratio
Receiver
Average Rx Sensitivity @ 1.25 Gb/s
(Gigabit Ethernet)
Average Rx Sensitivity @ 1.06 Gb/s
(1X Fibre Channel)
Stressed RX sens. =1.25 Gb/s
Average Received Power
Receiver Elec. 3 dB cutoff freq.
Optical Center Wavelength
Return Loss
LOS De-Assert
LOS Assert
LOS Hysteresis
Symbol
P
OUT
λ
σ
OMA
t
r
/ t
f
TX
Δ
DJ
TX
Δ
TJ
ER
R
SENS2
R
SENS1
Min
-9.5
1270
174
150
20
50
9
-19
-21
-14.5
0
1500
1600
-19
-30
0.5
260
-120
56.5
119
Typ
Max
-3
1360
3
Unit
dBm
nm
nm
μW
ps
dB/Hz
ps
ps
dB
dBm
dBm
dBm
dBm
MHz
nm
dB
dBm
dBm
dB
Ref.
1
2
2
2,3
4
5
6, 7
6, 7
Rx
MAX
λ
C
LOS
D
LOS
A
1265
12
Notes:
1. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
2. Also specified to meet curves in FC-PI-2 Rev. 10.0 Figure 18, which allow trade-off between
wavelength, spectral width and OMA.
3. Equivalent extinction ratio specification for Fibre Channel. Allows smaller ER at higher average
power.
4. Unfiltered, 20-80%. Complies with IEEE 802.3 (Gig. E) and FC 1x eye masks when filtered.
5. Measured with DJ-free data input signal. In actual application, output DJ will be the sum of input DJ
and
Δ
DJ.
6. Measured with conformance signals defined in FC-PI-2 Rev. 10.0 specifications.
7. Measured with PRBS 2
7
-1 at 10
-12
BER
©
Finisar Corporation April 12, 2007 Rev. A1
Page 4
FTLF1318P2xTL SFP Product Specification – April 2007
Finisar
V.
General Specifications
Parameter
Symbol
BR
BER
L
MAX1
L
MAX2
Min
1062
Typ
Max
1250
10
-12
Units
Ref.
Mb/sec 1
2
km
3, 4
km
3, 4
Data Rate
Bit Error Rate
Max. Supported Link Length on
9/125μm SMF @ 1X Fibre Channel
Max. Supported Link Length on
9/125μm SMF @ Gigabit Ethernet
10
10
Notes:
1. Gigabit Ethernet and 1x Fibre Channel compliant.
2. Tested with a PRBS 2
7
-1 test pattern.
3. Dispersion limited per FC-PI-2 Rev. 10
4. Attenuation of 0.55 dB/km is used for the link length calculations. Distances are indicative only.
Please refer to the Optical Specifications in Table IV to calculate a more accurate link budget based on
specific conditions in your application.
VI.
Environmental Specifications
Finisar 1310nm Industrial Temperature SFP transceivers have an operating temperature
range from -40°C to +85°C case temperature.
Parameter
Case Operating Temperature
Storage Temperature
Symbol
T
op
T
sto
Min
-40
-40
Typ
Max
85
100
Units
°C
°C
Ref.
VII.
Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of EN (IEC)
60950. Copies of certificates are available at Finisar Corporation upon request.
©
Finisar Corporation April 12, 2007 Rev. A1
Page 5
