Double Balanced Mixer
Octave Band
Electrical Specifications:
(1)
Model MO6xxG
RF 6.0 to 12.5 GHz
Conditions
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
RF to IF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(4)
RF (GHz)
6.0-12.5
6.0-12.5
6.0-12.5
LO (GHz)
5.0-15.0
5.0-15.0
5.0-15.0
5.0-15.0
5.0-15.0
5.0-15.0
DC-2500
IF (MHz)
DC-1000
DC-2000
DC-2500
Min
Specifications
Typical
4.5 dB
6.5 dB
8.8 dB
38 dB
38 dB
23 dB
+1 dBm
+3 dBm
+8 dBm
+12 dBm
+11 dBm
+13 dBm
+18 dBm
+22 dBm
+7 dBm
+10 dBm
+14 dBm
+19 dBm
MO63
MO64
MO66
MO67
MO63
MO64
MO66
MO67
MO63
MO64
MO66
MO67
Max
7.0 dB
8.5 dB
11.0 dB
Model MO6xxG
LO Power
3 = +7 dBm
4 = +10 dBm
6 = +14 dBm
7 = +19 dBm
Drop-In Module or
With SMA(F)
Connectors
M = Module
P = With Connectors
25 dB
25 dB
6.0-12.5
6.0-12.5
6.0-12.5
5.0-15.0
DC-2500
6.0-12.5
5.0-15.0
DC-2500
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system from -55˚C to +100˚C
with the nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss for IF frequencies greater than 10 MHz.
3. Conversion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
Typical
Performance
at 25˚C
MO6xxG
SPECTRUM
Outline: G
All dimensions are in inches and [mm].
