RF AMPLIFIER
MODEL
TM3114
Features
Low +5 Volt Supply
Wide 100 - 3000 MHz Bandwidth
Environmental Screening Available
Available as:
TM3114, 4 Pin TO-8 (T4)
TN3114, 4 Pin Surface Mount (SM3)
BX3114, SMA Connectorized Laser Seal
Housing (H1L)
Typical Intermodulation Performance at 25 ºC
Second Order Harmonic Intercept Point ...... +47 dBm (Typ.)
Second Order Two Tone Intercept Point ....... +42 dBm (Typ.)
Third Order Two Tone Intercept Point ........... +34 dBm (Typ.)
MIN/MAX
Ta = -55 ºC to +85 ºC
100 - 3000 MHz
19 Min.
+17 Min
-28 Max.
2.0:1 Max
2.0:1 Max.
4.0 Max.
+5
130 Max.
Specifications
CHARACTERISTIC
Frequency
Gain (dB)
Power @ 1 dB Comp. (dBm)
Reverse
Isolation (dB)
In
Out
Noise Figure (dB)
Power
Vdc
mA
VSWR
TYPICAL
Ta= 25 ºC
100 - 3000 MHz
21
+18
-30
1.8:1
1.8:1
2.5
+5
125
Absolute Maximum (No Damage) Ratings
Ambient Operating Temperature ................ -55ºC to +100 ºC
Storage Temperature ................................. -69ºC to +125 ºC
Case Temperature .................................................. +125 ºC
DC Voltage ........................................................... +8 Volts
Continuous RF Input Power .................................. +13 dBm
Short Term RF Input Power ...... 20 Milliwatts (1 Minute Max.)
Maximum Peak Power .................... 0.2 Watt (3
μsec
Max.)
Note:
Care should always be taken to effectively ground the case of each unit.
Revision: 7/17/2012
Typical Performance Data
