RF AMPLIFIER
MODEL
TM5119PM
Features
!
!
!
!
Superior Phase Noise Performance
Low Noise Figure: 2.25 dB Typical
Medium Output Power: +16 dBm Typical
Operating Temp. -55 ºC
to +85
ºC
TYPICAL
Ta= 25 ºC
5 - 500 MHz
15.5
+16
-19
<1.75:1
<1.75:1
2.25
+15
30
MIN/MAX
Ta = -55 ºC to +85 ºC
5 - 500 MHz
14.0 Min.
+14 Min.
-18 Max.
2.0:1 Max.
2.0:1 Max.
3.0 Max.
+15
35 Max.
Available as:
TM5119PM, 4 Pin TO-8 (T4)
TN5119PM, 4 Pin Surface Mount (SM3)
FP5119PM, 4 Pin Flatpack (FP4)
BX5119PM, Connectorized Housing (H1)
Typical Intermodulation Performance at 25 ºC
Second Order Harmonic Intercept Point ....... +49 dBm (Typ.)
Second Order Two Tone Intercept Point ........ +44 dBm (Typ.)
Third Order Two Tone Intercept Point ............ +32 dBm (Typ.)
Maximum Ratings
Ambient Operating Temperature ................ -55ºC to +100 ºC
Storage Temperature ................................. -62ºC to +125 ºC
Case Temperature .................................................. +125 ºC
DC Voltage .......................................................... +18 Volts
Continuous RF Input Power .................................. +13 dBm
Short Term RF Input Power ...... 50 Milliwatts (1 Minute Max.)
Maximum Peak Power .................... 0.5 Watt (3
µsec
Max.)
Guaranteed Phase Noise Performance
(dBc/Hz)
Frequency
100 Hz
1 kHz
10 kHz
100 kHz
1 MHz
Typical
-155
-170
-172
-173
-173
Guarantee (Min.)
-151
-166
-168
-169
-169
Specifications
CHARACTERISTIC
Frequency
Gain (dB)
Power @ 1 dB
Comp. (dBm)
Reverse
Isolation (dB)
In
Out
Noise Figure (dB)
Power
Vdc
mA
VSWR
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
17
16
15
14
13
Start 5 MHz
Stop 500 MHz
Gain (dB)
0
-10
-20
-30
-40
Reverse Isolation (dB)
-130
-140
-150
-160
Phase Noise (dBc/Hz)
Start 5 MHz
Stop 500 MHz
+18
+17
+16
+15
+14
Start 5 MHz
1 dB Comp. (dBm)
3
2
Noise Figure (dB)
-170
-180
-190
100
1k
10k
100k
1M
1
Stop 500 MHz
Start 5 MHz
Stop 500 MHz
_________Guarantee __ __ __ __Typical
Output VSWR
2.0
1.5
1.0
Start 5 MHz
Input VSWR
2.0
1.5
1.0
Stop 500 MHz
Start 5 MHz
Phase Noise Test Conditions:
Carrier Frequency: 200 MHz
Power Output: +16 dBm
Temperature: 25 ºC
Agilent ES5500 System
Stop 500 MHz
Legend
+25 ºC
+85 ºC - - - - - - -55 ºC
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532
3/31/04
www.SpectrumMicrowave.com
Spectrum Microwave · 2707 Black Lake Place · Philadelphia, Pennsylvania 19154 · PH (215) 464-4000 · Fax (215) 464-4001
