Transient Voltage Suppressors Array for ESD Protection
SLVU2.8
Description
The SLVU2.8 is designed to protect voltage sensitive
components from ESD and transient voltage events. Excellent
clamping capability, low leakage, and fast response time,
make these parts ideal for ESD protection on designs where
board space is at a premium.
Low Capacitance
SOT-23
Feature
u
u
u
u
u
u
u
400 Watts Peak Pulse Power per Line (tp=8/20μs)
Protects two line pairs (four lines)
Low capacitance
RoHS Compliant
IEC61000-4-2 (ESD)
±15kV
(air),
±8kV
(contact)
IEC61000-4-4 (EFT) 40A (5/50ηs)
IEC61000-4-5 (Lightning) 24A (8/20μs)
Functional Diagram
Applications
u
u
u
u
u
u
10/100 Ethernet
WAN/LAN Equipment
Laser Diode Protection
Switching Systems
Instrumentation
Base Stations
u
u
u
u
u
u
JEDEC SOT-23 Package
Molding Compound Flammability Rating : UL 94V-0
Weight 8.0 Milligrams (Approximate)
Quantity Per Reel : 3,000pcs
Reel Size : 7 inch
Lead Finish : Lead Free
Mechanical Characteristics
Mechanical Characteristics
Symbol
P
PP
T
L
T
STG
T
J
Parameter
Peak Pulse Power (tp=8/20μs waveform)
Lead Soldering Temperature
Storage Temperature Range
Operating Temperature Range
IEC61000-4-2 (ESD)
Air Discharge
Contact Discharge
IEC61000-4-4 (EFT)
IEC61000-4-5 ( Lightning )
Value
400
260 (10sec)
-55 to +150
-55 to +150
±15
±8
40
24
Units
W
ºC
ºC
ºC
KV
A
A
UN Semiconductor Co., Ltd.
Revision January 06, 2014
www.unsemi.com.tw
1/3
@ UN Semiconductor Co., Ltd. 2014
Specifications are subject to change without notice.
Please refer to www.unsemi.com.tw for current information.
Transient Voltage Suppressors Array for ESD Protection
SLVU2.8
Electrical Characteristics
(@ 25℃ Unless Otherwise Specified )
Device
Marking
328
V
RWM
(V)
(Max.)
2.8
V
B
(V)
(Min.)
3.0
I
T
(mA)
1
V
C
@5A
(Max.)
7
V
C
(Max.)
20
(@A)
24
Low Capacitance
Part Number
I
R
(μA)
(Max.)
1
C
(pF)
(Typ.)
3
SLVU2.8
Characteristic Curves
Fig1.
8/20μs Pulse Waveform
Fig2. ESD Pulse Waveform (according to IEC 61000-4-2)
100%
Percent of Peak Pulse Current %
90%
120
I
PP
- Peak Pulse Current - % of I
PP
100
80
60
40
t
d
=t I
PP
/2
20
0
0
5
10
15
t - Time (μs)
20
25
30
t
r
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
r
=8μs
t
d
=20μs
10%
tr = 0.7~1ns
30ns
60ns
Time (ns)
Fig3.
Power Derating Curve
100
90
80
% of Rated Power
70
60
50
40
30
20
10
0
0
20
40 60 80 100 120 140 160 180 200
Ambient Temperature
–
T
A
(ºC)
UN Semiconductor Co., Ltd.
Revision January 06, 2014
www.unsemi.com.tw
2/3
@ UN Semiconductor Co., Ltd. 2014
Specifications are subject to change without notice.
Please refer to www.unsemi.com.tw for current information.
Transient Voltage Suppressors Array for ESD Protection
SLVU2.8
SOT-23 Package Outline & Dimensions
Millimeters
Symbol
Min.
A
A1
b
c
D
E
e
L
H
E
0.89
0.01
0.37
0.09
2.80
1.20
1.78
0.35
2.10
Nom.
1.00
0.06
0.44
0.13
2.90
1.30
1.90
0.54
2.40
Max.
1.11
0.10
0.50
0.18
3.04
1.40
2.04
0.69
2.64
Low Capacitance
Inches
Min.
0.035
0.001
0.15
0.003
0.110
0.047
0.070
0.014
0.083
Nom.
0.040
0.002
0.18
0.005
0.114
0.051
0.075
0.021
0.094
Max.
0.044
0.004
0.020
0.007
0.120
0.055
0.081
0.029
0.104
Soldering Footprint
Symbol
X
X1
Y
Z
Millimeters
0.80
0.95
0.90
2.00
Inches
0.031
0.037
0.035
0.079
UN Semiconductor Co., Ltd.
Revision January 06, 2014
www.unsemi.com.tw
3/3
@ UN Semiconductor Co., Ltd. 2014
Specifications are subject to change without notice.
Please refer to www.unsemi.com.tw for current information.
