SURFACE-MOUNT CERAMIC CHIP INDUCTORS
AIMC SERIES
0805
FEATURES:
•
•
•
•
•
•
•
Construction: Ceramic
High Frequency Design
Avoid Crosstalk
Excellent Q Values
Excellent SRF
High Reliability
Excellent Thermal Stability
OPTIONS:
• Tape & Reel is Standard
(Qty: 3000 pcs.)
Bulk Packaging Available
for Smaller Quantities
• Tolerance: J=5%, K=10% is standard
Tighter Tolerances Available
COMMON APPLICATIONS:
•
•
•
•
•
•
•
Modems
Mobile Radios
Cordless Telephones
Global Positioning Systems
Wireless Communications Equipment
Networking System
Computer Products and Peripherals
STANDARD SPECIFICATIONS
Part
Number
L (µH)
J=±5%
K=±10%
S=±0.3nH
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
Q
Min
L.Q Test SRF
Freq
Min
(MHz) (MHz)
RDC
Max
(
Ω
)
IDC
Max
(mA)
PHYSICAL CHARACTERISTICS
L
0805 Series
AIMC-0805-R0015S
AIMC-0805-R0018S
AIMC-0805-R0022S
AIMC-0805-R0027S
AIMC-0805-R0033S
AIMC-0805-R0039S
AIMC-0805-R0047S
AIMC-0805-R0056S
AIMC-0805-R0068S
AIMC-0805-R0082S
AIMC-0805-R010J
AIMC-0805-R012J
AIMC-0805-R015J
AIMC-0805-R018J
AIMC-0805-R022J
AIMC-0805-R027J
AIMC-0805-R033J
AIMC-0805-R039J
AIMC-0805-R047J
AIMC-0805-R056J
AIMC-0805-R068J
AIMC-0805-R082J
AIMC-0805-R10J
AIMC-0805-R12J
AIMC-0805-R15J
AIMC-0805-R18J
AIMC-0805-R22J
AIMC-0805-R27J
AIMC-0805-R33J
AIMC-0805-R39J
AIMC-0805-R47J
W
13
13
13
13
13
15
15
15
15
15
16
16
17
17
17
18
18
18
18
19
19
20
18
19
20
20
20
20
20
20
20
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
50
6000
6000
6000
6000
6000
5400
4500
4000
3650
3000
2500
2450
2000
1750
1700
1550
1350
1300
1200
1150
1000
850
600
500
500
400
350
300
250
250
200
0.10
0.10
0.10
0.10
0.13
0.15
0.20
0.23
0.25
0.28
0.30
0.35
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.80
0.90
1.00
1.50
1.50
2.10
2.10
3.00
3.00
3.50
3.50
600
600
600
600
600
600
400
400
400
400
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
200
200
200
200
BW
T
Dimensions: Inches (mm)
Length (L)
Width (W)
Thickness (T)
Termination (BW)
AIMC-0805
0.079+0.012,-0.004
(2.0+3,-0.1)
0.049±0.008
(1.25±0.2)
0.033±0.012
(0.85±0.3)
0.02±0.012
(0.5±0.3)
R0015S~R0082K: T=0.023±0.008 (0.58 ±0.2)
R047J~R47J : T=0.033±0.012 (0.84 ±0.3)
R010J~R039J : T=0.039±0.012 (1.0 ±0.3)
TECHNICAL INFORMATION:
• Testing: HP4291A
• Solderability: 90% of the terminal electrode shall
be covered
Preheat: @135°C±15°C for 60 seconds
• Solder Temperature: 230±5°C
• Operating Temperature: -55°C to +125°C
Note: All specifications subject to change without notice.
