477KXM010MME datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 477KXM010MME

477KXM010MME: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 10V, 20% +Tol, 20% -Tol, 470uF, Through Hole Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size428KB，5 Pages; ManufacturerIllinois Capacitor; Websitehttp://www.illinoiscapacitor.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

477KXM010MME Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 10V, 20% +Tol, 20% -Tol, 470uF, Through Hole Mount, RADIAL LEADED

477KXM010MME Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Illinois Capacitor
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	470 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
ESR	670 mΩ
leakage current	0.047 mA
Manufacturer's serial number	KXM
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package shape	CYLINDRICAL PACKAGE
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	10 V
ripple current	640 mA
surface mount	NO
Delta tangent	0.19
Terminal shape	WIRE

Preview

Download Datasheet

View All

KXM

FEATURES

High Ripple Current

High Frequency

Extended Life

SPECIFICATIONS

Capacitance Tolerance

Operating Temperature Range

Dissipation Factor

120Hz, 20°C

WVDC

tan

+105°C Low Impedance

Radial Lead Aluminum

Electrolytic Capacitors

For switching regulators and extended life applications

Voltage Range: 6.3 WVDC to 100 WVDC

Capacitance Range: .47 µF to 15000 µF

±20% at 120Hz, 20°C

-55°C to + 105°C

6.3

.22

.19

.16

.14

.12

.08

100

.08

Note:

For above D.F. specifications, add .02 for every 1,000 µF above 1,000 µF

WVDC

Impedance Ratio

(Max.) @120Hz

-25°C/20°C

-40°C/20°C

WVDC

Leakage Current

Time

6.3

100

< 100 WVDC

2 minutes

.01 CV or 3µA

whichever is greater

Load Life

5000 hours at +105°C with rated WVDC and rated ripple current

(4000 hours for D=10, 3000 hours for D=8, 2000 hours for D≤6.3)

Capacitors will meet the requirements listed below.

Capacitance change

Dissipation factor

Leakage current

≤

25% of initial measured value

≤

200% of initial specified value

≤100%

of specified value

1,000 hours at +105°C with no voltage applied.

Units will meet load life specifications

Frequency (Hz)

Capacitance (µF)

C≤33

47<C≤330

470<C≤1000

C>1000

.45

.60

.65

.75

120

.55

.70

.75

.80

.75

.85

.90

.95

10K

.91

.95

.98

1.0

100K

1.0

Shelf Life

Temperature (°C)

+105

1.0

+85

1.41

+70

1.65

Ripple Current Multipliers

SPECIAL ORDER OPTIONS

•

Special tolerances: ±10% (K), -10% + 30% (Q)

(See pages 37 thru 41)

•

Tape and Reel/Ammo-Pack

•

Cut, Formed, Cut and Formed, and Snap In Leads

3757 W. Touhy Ave., Lincolnwood, IL 60712 • (847) 675-1760 • Fax (847) 673-2850 • www.illcap.com

477KXM010MME Related Products

	477KXM010MME	128KXM050MQW	70100.8760.25LF	227KXM050MME
Description	Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 10V, 20% +Tol, 20% -Tol, 470uF, Through Hole Mount, RADIAL LEADED	Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 50V, 20% +Tol, 20% -Tol, 1200uF, Through Hole Mount, RADIAL LEADED	Fixed Resistor, Wire Wound, 0.33W, 0.876ohm, 300V, 0.25% +/-Tol, -90,90ppm/Cel,	Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 50V, 20% +Tol, 20% -Tol, 220uF, Through Hole Mount, RADIAL LEADED
Is it Rohs certified?	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Number of terminals	2	2	2	2
Maximum operating temperature	105 °C	105 °C	145 °C	105 °C
Minimum operating temperature	-55 °C	-55 °C	-65 °C	-55 °C
Package shape	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE	TUBULAR PACKAGE	CYLINDRICAL PACKAGE
Is it lead-free?	Lead free	Lead free	-	Lead free
capacitance	470 µF	1200 µF	-	220 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	-	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)	ALUMINUM (WET)	-	ALUMINUM (WET)
ESR	670 mΩ	138 mΩ	-	754 mΩ
leakage current	0.047 mA	0.6 mA	-	0.11 mA
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	-	THROUGH HOLE MOUNT
negative tolerance	20%	20%	-	20%
polarity	POLARIZED	POLARIZED	-	POLARIZED
positive tolerance	20%	20%	-	20%
Rated (DC) voltage (URdc)	10 V	50 V	-	50 V
ripple current	640 mA	2710 mA	-	1050 mA
surface mount	NO	NO	-	NO
Delta tangent	0.19	0.12	-	0.1
Terminal shape	WIRE	WIRE	-	WIRE
