THROUGH-HOLE AXIAL
SHIELDED INDUCTORS
AIAS-04 SERIES
FEATURES:
•
•
•
•
•
•
•
Shielded Construction
Wire-wound Design
Excellent Heat Resistance
Excellent Environmental Characteristics
High Reliability
Excellent Inductance to Q Ratios
Inductance Values to 100000 µH
OPTIONS:
• Bulk Packaging is Standard
(Qty: 2500 pcs.)
Tape and Real Available
• Tolerance: 10% is Standard,
Tighter Tolerances Available
COMMON APPLICATIONS:
•
•
•
•
Telecommunications Systems
Disk Drives
Computer Products and Peripherals
Medical Equipment
STANDARD SPECIFICATIONS
Part
Number
AIAS-04 Series
AIAS-04-R10K
AIAS-04-R12K
AIAS-04-R15K
AIAS-04-R18K
AIAS-04-R22K
AIAS-04-R27K
AIAS-04-R33K
AIAS-04-R39K
AIAS-04-R47K
AIAS-04-R56K
AIAS-04-R68K
AIAS-04-R82K
AIAS-04-1R0K
AIAS-04-1R2K
AIAS-04-1R5K
AIAS-04-1R8K
AIAS-04-2R2K
AIAS-04-2R7K
AIAS-04-3R3K
AIAS-04-3R9K
AIAS-04-4R7K
AIAS-04-5R6K
AIAS-04-6R8K
AIAS-04-8R2K
AIAS-04-100K
AIAS-04-120K
AIAS-04-150K
AIAS-04-180K
AIAS-04-220K
AIAS-04-270K
AIAS-04-330K
AIAS-04-390K
AIAS-04-470K
AIAS-04-560K
AIAS-04-680K
AIAS-04-820K
AIAS-04-101K
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
50
50
50
50
50
50
47
47
47
45
43
41
42
43
41
42
42
41
41
41
42
42
42
46
46
50
50
50
50
50
50
50
55
55
55
55
65
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
400
400
400
400
400
400
325
290
264
249
221
200
156
144
128
121
108
96
88
84
72
69
62
58
53
47
41
43
38
36
33
29
26
25
23
14
12
.026
.029
.034
.044
.056
.090
.122
.161
.218
.290
.382
.450
.054
.070
.096
.107
.142
.184
.260
.354
.468
.511
.750
.828
1.27
1.76
2.30
.667
.742
.850
.928
1.28
1.48
1.64
2.20
1.96
2.28
3000
2860
2600
2300
2050
1625
1400
1220
1060
900
790
725
2080
1840
1560
1480
1290
1130
950
815
710
680
560
535
432
368
325
596
565
526
505
429
400
380
328
349
322
L
µH
Tol
%
Q
Min
Test
Freq
MHz
SRF
MHz
Min
RDC
Ω
Max
IDC
Max
mA
Part
Number
AIAS-04 Series
AIAS-04-121K
AIAS-04-151K
AIAS-04-181K
AIAS-04-221K
AIAS-04-271K
AIAS-04-331K
AIAS-04-391K
AIAS-04-471K
AIAS-04-561K
AIAS-04-681K
AIAS-04-821K
AIAS-04-102K
AIAS-04-122K
AIAS-04-152K
AIAS-04-182K
AIAS-04-222K
AIAS-04-272K
AIAS-04-332K
AIAS-04-392K
AIAS-04-472K
AIAS-04-562K
AIAS-04-682K
AIAS-04-822K
AIAS-04-103K
AIAS-04-123K
AIAS-04-153K
AIAS-04-183K
AIAS-04-223K
AIAS-04-273K
AIAS-04-333K
AIAS-04-393K
AIAS-04-473K
AIAS-04-563K
AIAS-04-683K
AIAS-04-823K
AIAS-04-104K
L
µH
Tol
%
Q
Min
Test
Freq
MHz
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.079
.079
.079
.079
.079
.079
.079
.079
.079
.079
.079
SRF
MHz
Min
11
10
10
9.4
8.0
7.3
6.9
6.5
6.0
5.6
4.8
4.5
2.6
2.5
2.3
2.2
2.1
2.0
1.8
1.7
1.6
1.5
1.4
1.3
.88
.78
.72
.57
.46
.42
.42
.37
.36
.35
.34
.32
RDC
Ω
Max
2.45
2.79
3.08
3.48
4.55
5.10
5.62
6.45
8.00
8.85
10.4
12.1
15.1
16.8
19.1
22.0
25.1
33.3
36.8
51.2
54.6
62.0
86.6
93.1
84.0
97.0
104
145
195
222
242
317
362
410
440
484
IDC
Max
mA
311
294
277
251
231
215
205
192
174
163
151
139
125
119
111
103
97
85
80
68
66
62
52
50
53
49
48
40
34
32
31
27
25
24
23
22
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
47000
56000
68000
82000
100000
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
65
65
65
65
65
65
65
70
70
75
70
65
70
70
70
70
70
70
70
70
70
70
70
70
50
50
50
50
50
50
50
50
50
50
50
50
TECHNICAL INFORMATION:
• Testing: (Equivalent acceptable)
Inductance - HP4342A
RDC: QuadTech 1880 Milliohmmeter - Q: HP4342A - SRF: HP4191A
• IDC Max: Based on coil temperature rise not to
exceed 35°C at 90°C ambient temperature
• Operating temperature: -55°C to + 125°C
• Storage temperature: -55°C to +85°C
• Shielding: 5% coupling maximum with 2 units side by side @ 1KHz
• Marking: EIA 5 band color code
Note: All specifications subject to change without notice.
