SURFACE-MOUNT CERAMIC CHIP INDUCTORS
AIMC SERIES
0603
FEATURES:
•
•
•
•
•
•
•
Construction: Ceramic
High Frequency Design
Avoid Crosstalk
Excellent Q values
Excellent SRF
High Reliability
Excellent Thermal Stability
OPTIONS:
• Tape & Reel is Standard
(Qty: 4000 pcs.)
Bulk Packaging Available
for Smaller Quantities
• Tolerance: J=5%, K=10% is standard
Tighter Tolerances Available
COMMON APPLICATIONS:
•
•
•
•
•
•
•
Modems
Mobile Radios
Cordless Telephones
Global Positioning Systems
Wireless Communications Equipment
Networking System
Computer Products and Peripherals
STANDARD SPECIFICATIONS
Part
Number
0603 Series
AIMC-0603-R0015S
AIMC-0603-R0018S
AIMC-0603-R0022S
AIMC-0603-R0027S
AIMC-0603-R0033S
AIMC-0603-R0039S
AIMC-0603-R0047S
AIMC-0603-R0056S
AIMC-0603-R0068S
AIMC-0603-R0082S
AIMC-0603-R010J
AIMC-0603-R012J
AIMC-0603-R015J
AIMC-0603-R018J
AIMC-0603-R022J
AIMC-0603-R027J
AIMC-0603-R033J
AIMC-0603-R039J
AIMC-0603-R047J
AIMC-0603-R056J
AIMC-0603-R068J
AIMC-0603-R082J
AIMC-0603-R10J
AIMC-0603-R12J
AIMC-0603-R15J
AIMC-0603-R18J
AIMC-0603-R22J
PHYSICAL CHARACTERISTICS
RDC
Max
(
Ω
)
IDC
Max
(mA)
L
L (µH)
J=±5%
K=±10%
S=±0.3nH
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.100
0.120
0.150
0.180
0.220
Q
Min
L.Q Test SRF
Freq
Min
(MHz) (MHz)
W
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
14
14
14
14
15
15
15
15
15
15
15
15
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
10000
9800
7600
7000
6200
5600
4800
4600
4200
3600
3200
2800
2600
2400
2000
1900
1600
1400
1200
1000
900
800
700
600
500
400
400
0.10
0.12
0.20
0.20
0.20
0.20
0.20
0.30
0.30
0.30
0.50
0.50
0.60
0.60
0.60
0.80
0.80
0.80
1.00
1.00
1.00
1.00
1.00
1.20
1.20
1.30
1.20
500
500
500
500
500
500
500
500
500
500
300
300
300
300
300
300
300
300
300
200
200
200
200
300
300
300
300
BW
T
Dimensions: Inches (mm)
AIMC-0603
Length (L)
Width (W)
Thickness (T)
Termination (BW)
0.063±0.006
(1.6±0.15)
0.031±0.006
0.8±0.15)
0.031±0.006
(0.8±0.15)
0.012±0.008
(0.3±0.2)
TECHNICAL INFORMATION:
• Testing: HP4291A
• Solderability: 90% of the terminal electrode shall
be covered
Preheat: @135°C±15°C for 60 seconds
• Solder Temperature: 230±5°C
• Operating Temperature: -55°C to +125°C
Note: All specifications subject to change without notice.
