SPECIFICATION
CHARACTER TYPE
DOT MATRIX LCD MODULE
ITEM NUMBER:
ESTABLISHED DATE:
INITIAL ISSUED DATE:
DATASHEET VERSION:
FDCC1602N-FLYYBW-91LE
1999.06
2005.05
2008 VERSION
This item supplied to Farnell by MIDAS COMPONENTS
MIDAS COMPONENTS LTD
Address: Electra House, 32 Southtown Road, Great
yarmouth, Norfolk, England, NR31 ODU
Email: sales@midascomponents.co.uk
Website: www.midascomponents.co.uk
Tel: +44 (0)1493 602602 Fax: +44 (0)1493 665111
UV
F
F
F
HC
RoHS
70 C
-20 C
3.0V
ISSUED BY:
COPYRIGHT
CHECKED BY:
APPROVED BY:
2000 ~ 2009 FORDATA ELECTRONIC CO., LTD. ALL RIGHTS RESERVED
BOOKBINDING AREA
FORDATA ELECTRONIC CO.,LTD
STANDARD
DOC.
PROFESSIONAL LCD SUPPLIER FROM CHINA
DATASHEET STATEMENT
1.
The following icons are absolutely designed by FORDATA independently in 2007-SEP. They are not in common
use in the LCD industry yet but just used for marking out FORDATA products’ characteristics quickly and
simply without any special meaning. FORDATA reserves the composing right and copyright.
No one else is allowed to adopt these icons without FORDATA’s approval.
2.
The ISO9001 logo used in this document is authorized by SGS (www.sgs.com). FORDATA had already
successfully passed the strict and professional ISO9001:2000 Quality Management System Certification and
got the certificate (No.: CN07/00404)
3.
The technologies/techniques/crafts which denoted by the following icons are not exclusively owned by FORDATA,
but also shared by FORDATA’s LCD strategic cooperators, however all these technologies/techniques/crafts have
been finally confirmed by FORDATA’s professional engineers and QC department.
4.
As the difference in test standard and test conditions, also FORDATA’s insufficient familiarity with the actual LCD
using environment, all the referred information in this DATASHEET (including the icons) only have two functions:
4.1: providing quick reference when you are judging whether or not the product meets your requirements.
4.2: listing out definitely the tolerance.
FORDATA declares seriously:
you should first test the corresponding sample(s) before signing the formal FORDATA
SAMPLE APPROVAL document rather than consider this DATASHEET as the standard for judging whether or not the
LCD meets your requirements. Once you instruct FORDATA to a mass-production without definite demand for
providing sample before, FORDATA will disclaim all responsibility if the mass-production is proved not meeting with
your requirements.
5.
The sequence of the icons is random and doesn’t indicate the importance grade.
6.
Icons explanation
FORDATA’s 2006 version logo. FORDATA is an integrated manufacturer of flat
panel display (FPD). FORDATA supplies TN, HTN, STN, FSTN monochrome
LCD panel; COB, COG, TAB LCD module; and all kinds of LED backlight.
F
F
F
HC
FAST RESPONSE TIME
This icon on the cover indicates the product
is with high response speed; Otherwise not.
HIGH CONTRAST
This icon on the cover indicates the product
is with high contrast; Otherwise not.
PROTECTION CIRCUIT
This icon on the cover indicates the product
is with protection circuit; Otherwise not.
LONG LIFE VERSION
This icon on the cover indicates the product
is long life version (over 9K hours guaranteed);
Otherwise not.
WIDE VIEWING SCOPE
This icon on the cover indicates the product
is with wide viewing scope; Otherwise not.
RoHS COMPLIANCE
This icon on the cover indicates the product
meets ROHS requirements; Otherwise not.
3TIMEs 100% QC EXAMINATION
This icon on the cover indicates the product
has passed FORDATA’s thrice 100% QC.
Otherwise not.
UV
Anti UV VERSION
This icon on the cover indicates the product
is against UV line. Otherwise not.
OPERATION TEMPERATURE RANGE
This icon on the cover indicates the operating
temperature range (X-Y).
TWICE SELECTION OF LED MATERIALS
This icon on the cover indicates the LED had passed
FORDATA’s twice strict selection which promises the
product’s identical color and brightness; Otherwise not.
N SERIES TECHNOLOGY (2008 developed)
FORDATA adopts new structure, new craft, new
technology and new materials inside both LCD
module and LCD panel to improve the "RainBow"
RoHS
YC
XC
3.0V
Vlcm = 3.0V
This icon on the cover indicates the product
can work at 3.0V exactly; otherwise not.
N
BOOKBINDING AREA
FORDATA ELECTRONIC CO.,LTD
STANDARD
REVISION RECORD
DOC.
PROFESSIONAL LCD SUPPLIER FROM CHINA
PAGE 1/20
NO.
DATE
2005.05
2007.04
2008.01
2008.10
2008.10
DESCRIPTION
INITIAL ISSUED
Added further information of LED backlight
Adopt logos on the cover for fast reference
Deleted “N = No Ic ” from CODE2
Added CODE “B” for DFSTN version in CODE7
ITEM
PAGE
APPROVED
1
2
3
4
5
ALL
4
-
-
-
ALL
4/20
Cover
Code System
Code System
LU BOO
BOOKBINDING AREA
FORDATA ELECTRONIC CO.,LTD
1
FD
2
C
3
C
4
08
5
01
6
A
7
F
8
L
STANDARD
DOC.
PROFESSIONAL LCD SUPPLIER FROM CHINA
9
Y
10
Y
CODE SYSTEM
STANDARD COB
11
B
12
W
13
5
14
2
PAGE
1/1
15
L
16
E
No.
1
2
3
4
5
6
7
REMARKS
COMPANY ABBRAVIATED
IC packing
LCM type
Chyaracter
Graphic
Character
Graphic
Serial Number
Polarizer type
FD = FORDATA
C = Chip On Board
C = Character
DESCRIPTION
G = Chip On Glass
G = Graphic
T = TAB
08, 10, 12, 16, 20, 24, 40, = Character number Per line
80, 100, 120, 122, 128, 160 ... ... = Row Dots Quantity
01, 02, 04, = Character Lines
32, 64, 80, 128, 160 ... ... =Column Dots Quantity
A~Z
R = Positive Reflective
F = Positive Transflective
M = Positive Transmissive
N = Negative Transmissive
E = Negative, Transflective
B = Negative, Dual optical compensation (for FSTN type only)
N = No Backlight
L = Array Type LED Backlight
E = EL backlight without Invertor
C = CCFL backlight without Invertor
N = No Backlight
R = Red
B = Blue
T = TN
G = Gray STN
B = Bottom 6:00
S = Edge Type LED Backlight
F = EL backlight with Invertor
T = CCFL backlight with Invertor
W = White
C = Blue-Green
Y = Yellow-Green STN
F = FSTN
R = Right 3:00
L = Left 9:00
8
Backlight type
9
Backlight color
Y = Yellow-Green
A = Amber
G = Green
H = HTN
B = Blue STN
T = Top 12:00
10
11
12
LCD panel type
Viewing angle
Operation temperature range
S = 0 C ~ 50 C (Single Supply Voltage)
D = 0 C ~ 50 C (Dual Supply Voltage)
W = -20 C ~ 70 C (Single Supply Voltage) H = -20 C ~ 70 C (Dual Supply Voltage)
T = -30 C ~ 80 C (Single Supply Voltage) E = -30 C ~ 80 C (Dual Supply Voltage)
1 : Vlcm = 3.0V, No / EL / CCFL Backlight
or Vlcm = 3.0V, Vled = LED voltage, (Via AK)
2 : Vlcm = 3.6V, Vled = 5.0V (Not via AK)
3 : Vlcm = 3.6V, Vled = LED voltage, (Not via AK)
4 : Vlcm = 5.0V, Vled = LED voltage, (Not via AK)
5 : Vlcm = 5.0V, Vled = 5.0V (Not via AK)
6 : Vlcm = 5.0V, No / EL / CCFL Backlight
or Vlcm = 5.0V, Vled = LED voltage, (Via AK)
7 : Vlcm = 3.6V, No / EL / CCFL Backlight
or Vlcm = 3.6V, Vled = LED voltage, (Via AK)
8 : Vlcm = 3.0V, Vled = 5.0V
9 : Vlcm = 3.0V, Vled = LED voltage, (Not via AK)
0 = PIN1 LED-, PIN2 LED+
1 = PIN15(17/19) LED+, PIN16(18/20) LED-
2 = PIN15(17/19) LED-, PIN16(18/20) LED+
3 = PIN15(17/19) LED+, PIN16(18/20) NC
4 = PIN15(17/19) NC, PIN16(18/20) LED+
5 = PINA LED+, PINK LED-
6 = No / EL / CCFL Backlight
X = SAMSUNG
T = TOSHIBA
Q = ASLIC
L = SUNPLUS
E = EPSON
N = CIMTEK
S = SITRONIX
H = HOLTEK
P = PRINCETON
13
Driving Voltage
14
Backlight Connect Method
15
IC Manufacturer
16
Font Set
R = English - Russia
U = English - Europe
K = English - Europe
E = English - Japanese
H = English - Hebrew
N = NO FONT SET
BOOKBINDING AREA
FORDATA ELECTRONIC CO.,LTD
STANDARD
DOC.
PROFESSIONAL LCD SUPPLIER FROM CHINA
CONTENTS
PAGE 3/20
1. GENERAL SPECIFICATIONS -------------------------------------------- Page 4
2. MECHANICAL SPECIFICATIONS -------------------------------------- Page 4
3. ABSOLUTE MAXIMUM RATINGS -------------------------------------- Page 4
4. ELECTRONICAL CHARACTERISTIC --------------------------------- Page 4
5. OPTICAL CHARACTERISTICS ------------------------------------------ Page 5
6.
ELECTRICAL SPECIFICATIONS----------------------------------------
Page 6
7. EXTERNAL DIMENSION--------------------------------------------------- Page 8
8. PIN ASSIGNMENT ---------------------------------------------------------- Page 9
9. POWER SUPPLY ------------------------------------------------------------
Page 9
10. REFLECTOR OF SCREEN AND DDRAM ADDRESS -------------- Page 9
11. INSTRUCTION TABLE --------------------------------------------------- Page 10
12. INSTRUCTION DESCRIPTION ------------------------------------------- Page 11
13. CGRAM ----------------------------------------------------------------------- Page 15
14. DDRAM ----------------------------------------------------------------------- Page 15
15. INITIALIZATION --------------------------------------------------------------- Page 16
16. INTERFACE TO MPU -------------------------------------------------------- Page 18
17. FONT MAP ------------------------------------------------------------------- Page 19
18. PACKING DETAIL --------------------------------------------------------- Page 20
