SOLID TANTALUM ELECTROLYTIC CAPACITORS
F97
Resin-molded Chip,
High Reliability
(High temperature /
moisture resistance) Series
Specifications
Item
Category
Temperature Range
Capacitance Tolerance
Performance Characteristics
--55 ~ +125
˚C
(Rated temperature : 85
˚C
.)
± 20%, ± 10% (at 120Hz)
~1.5 µF
4% Max.
2.2 ~68 µF 6% Max. (at 120Hz)
100 µF~
8% Max.
• After 1 minute' s application of rated voltage,leakage current at 20˚C
is not more than 0.01CV or 0.5 µA, whichever is greater.
• After 1 minute' s application of rated voltage,leakage current at 85˚C
is not more than 0.1CV or 5 µA,whichever is greater.
• After 1 minute' s application of derated voltage,leakage current at
125˚C is not more than 0.125CV or 6.3 µA,whichever is greater.
+15% Max. (at +125
˚C
)
+10% Max. (at +85
˚C
)
--10% Max. (at --55
˚C
)
At 85
˚C
, 85% R.H.,For 1000 hours (No voltage applied)
Capacitance Change
• • • • • •
Within ±10% of initial value
Dissipation Factor
• • • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • •
125% or less of initial specified value
After 500 hour' s application of rated voltage in series with a 33
Ω
resistor at 60
˚C
,90~95% R.H.,capacitors meet the characteristics
requirements listed below.
Capacitance Change
• • • • • •
Within ±10% of initial value
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • •
125% or less of initial specified value
At --55
˚C
/ +125
˚C
,For 30 minutes each,1000 cycles
Capacitance Change
• • • • • •
Within ± 5% of initial value
Dissipation Factor
• • • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • • •
Initial specified value or less
At 260
˚C
,reflowing capacitors for 10 seconds Max.
Capacitance Change
• • • • • •
Within ± 5% of initial value
Dissipation Factor
• • • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • • •
Initial specified value or less
After immersing capacitors completely into a solder pot at
245
˚C
for 2~3 seconds,more than 3/4 of their electrode area
shall remain covered with new solder.
After application of surge in series with a 33
Ω
resistor at the
rate of 30 seconds ON, 30 seconds OFF,for 1000 successive
test cycles at 85
˚C
,capacitors meet the characteristics
requirements listed below.
Capacitance Change
• • • • • •
Within ± 5% of initial value
Dissipation Factor
• • • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • • •
Initial specified value or less
After 2000 hours' application of rated voltage in series with a
3
Ω
resistor at 85
˚C
,or derated voltage in series with a 3
Ω
resistor at 125
˚C
,capacitors meet the characteristic
requirements listed below.
Capacitance Change
• • • • • •
Within ±10% of initial value
Dissipation Factor
• • • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • • •
Initial specified value or less
After Applying the pressure load of 5N
for 10 ± 1 seconds horizontally to the
center of capacitor side body which
has no electrode and has been
5N (0.51kg
•
f)
soldered beforehand on an aluminum
For 10
±
1 seconds
substrate,there shall be found neither
exfoliation nor its sign at the terminal
electrode.
Keeping a capacitor surface-mounted on a substrate upside
down and supporting the substrate at both of the opposite
bottom points 45mm apart from the center of the capacitor, the
pressure strength is applied with a
20
specified jig at the center of the
R230
substrate so that the substrate may
bend by 1mm as illustrated.
Then,there shall be found no
45
45
remarkable abnormality on the
capacitor terminals.
Dissipation Factor
Leakage Current∗
Capacitance Change
by Temperature
Type numbering system (Example : 16V 3.3 µF)
Damp Heat
1
2
3
4
5
6
7
8
9
10
11
Taping code
(Refer to page 213 for details)
Case code
Capacitance tolerance
Rated Capacitance Rated voltage
Series
F 9 7 1 C 3 3 5 M B
Load Humidity
Drawing
Temperature Cycles
A
•
B Case
L
H
W
1
L
C
•
N Case
W
1
H
Resistance
to Soldering Heat
W
2
S
S
S
S
W
2
Solderability
Dimensions
Case code
A
B
C
N
3.2
3.5
6.0
7.3
L
± 0.2
± 0.2
± 0.2
± 0.2
W
1
1.6
2.8
3.2
4.3
± 0.2
± 0.2
± 0.2
± 0.2
W
2
1.2
2.2
2.2
2.4
± 0.1
± 0.1
± 0.1
± 0.1
1.6
1.9
2.5
2.8
H
± 0.2
± 0.2
± 0.2
± 0.2
S
(mm)
Surge
∗
0.8 ± 0.2
0.8 ± 0.2
1.3 ± 0.2
1.3 ± 0.2
Endurance
∗
Marking
A Case
C105
B Case
3.3
16r
C Case
10
16r
N Case
47
10r
Shear Test
Month code
Rated voltage
(Voltage code)
Rated Capacitance
(Capacitance code ) Rated voltage (V) Rated Capacitance (µF)
Standard ratings
Cap.
(
µ
F)
V
Code
4
0G
6.3
0J
10
1A
16
1C
20
1D
25
1E
35
1V
A
A
A
A
Terminal Strength
0.15
0.22
0.33
0.47
0.68
1
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
154
234
334
474
684
105
155
225
335
475
685
106
156
226
336
476
686
107
157
C
A
A
A
B
B
B
C
C
•
∗
As for the surge and derated voltage at 125
˚C
, refer to page 212 for details.
A
A
A
A
A
A
A
B
B
B
C
C
C
N
•
B
B
B
C
C
C
A
B
A
B
A
B
B
C
C
C
N
N
N
C
N
N
B
A
A
B
B
B
C
C
C
N
•
C
C
N
N
N
N
N
N
N
N
N
N
CAT.8100S
